Finder 48 Series Interface Relay, DIN Rail Mount, 12V dc Coil, SPDT, 1-Pole, 10A Load
- RS Stock No.:
- 123-2802
- Mfr. Part No.:
- 48.P3.7.012.0050SPA
- Brand:
- Finder
34 In stock - FREE next working day delivery available
Added
Price Each
£15.73
(exc. VAT)
£18.88
(inc. VAT)
| Units | Per unit |
| 1 + | £15.73 |
- RS Stock No.:
- 123-2802
- Mfr. Part No.:
- 48.P3.7.012.0050SPA
- Brand:
- Finder
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
48 Series
Finder 48 series relay interface modules are an ideal interface for PLC and electronic systems.
Features and Benefits
Contact resistance: 50mΩ
Mechanical life: AC versions; 10 x 106 operations, DC versions; 20 x 106 operations
Dimensions: H78.6mm, W15.8mm, D76mm
Instant ejection of relay using plastic retaining clip
Supply status indication and EMC coil suppression module
Push-in and screw terminals
Mechanical life: AC versions; 10 x 106 operations, DC versions; 20 x 106 operations
Dimensions: H78.6mm, W15.8mm, D76mm
Instant ejection of relay using plastic retaining clip
Supply status indication and EMC coil suppression module
Push-in and screw terminals
Replacement relays stock no. 351-572 etc are available (Finder 40 Series), and should be selected such that the coil voltage, contact configuration and rating match the original type
Approvals
BBJ; BEAB; CSA; DEMKO; FIMKO; GOST; NEMKO; RINA; SEMKO; SEV; UL recognised component for Canada; VDE
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Load Current Rating | 10A |
| Minimum Input Voltage | 250V ac |
| Maximum Input Voltage | 400V ac |
| Switching Voltage | 250 V ac → 400V ac |
| Terminal Type | Push In |
| Depth | 75.3mm |
| Height | 95.5mm |
| Length | 15.8mm |
| Series | 48 Series |
| Contact Material | Silver Alloy |
| Input Current | 41mA |
| Relay Switching Classification | General Purpose Relay |
| Standards Met | CE, CSA, CULus, EAC, EZU, GOST, IMQ, LCIE, LIoyd's Register, RINA, VDE |
| Special Features | AC Coils or DC Sensitive Coils, Identification Label, Supply Status Indication & EMC Coil Suppression Module as Standard |
| Operating Temperature Range | -40 → +70°C |
| Turn On Time | (dc) 12 ms, (ac) 7ms |
| Dimensions | 15.8 x 75.3 x 95.5mm |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -40°C |
| Turn Off Time | (dc) 12 ms, (ac) 4ms |
