TE Connectivity IM46 Series Electromechanical Interface Relay, Surface, 12V dc Coil, DPDT

RS Stock No.:: 527-802
Distrelec Article No.:: 301-19-724
Mfr. Part No.:: 6-1462037-7
Brand:: TE Connectivity

TE Connectivity IM46 Series Electromechanical Interface Relay, Surface, 12V dc Coil, DPDT

Subtotal (1 unit)*

£2.91

(exc. VAT)

£3.49

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	£2.91

*price indicative

RS Stock No.:: 527-802
Distrelec Article No.:: 301-19-724
Mfr. Part No.:: 6-1462037-7
Brand:: TE Connectivity

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	TE Connectivity
	Coil Resistance	1440Ω
	Product Type	Electromechanical Interface Relay
	Coil Voltage	12V dc
	Contact Configuration	DPDT
	Mount Type	Surface
	Series	IM46
	Terminal Type	Surface Mount
	Switching Current	2A
	Switching AC Voltage	250V ac
	Minimum Operating Temperature	-40°C
	Switching DC Voltage	12V dc
	Contact Material	Ruthenium, Palladium
	Maximum Operating Temperature	85°C
	Height	5.65mm
	Standards/Approvals	2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU Compliant, RoHS, VDE
	Length	10mm
	Width	6mm

	Select all
	Brand TE Connectivity
	Coil Resistance 1440Ω
	Product Type Electromechanical Interface Relay
	Coil Voltage 12V dc
	Contact Configuration DPDT
	Mount Type Surface
	Series IM46
	Terminal Type Surface Mount
	Switching Current 2A
	Switching AC Voltage 250V ac
	Minimum Operating Temperature -40°C
	Switching DC Voltage 12V dc
	Contact Material Ruthenium, Palladium
	Maximum Operating Temperature 85°C
	Height 5.65mm
	Standards/Approvals 2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU REACH Regulation (EC) No. 1907/2006, EU RoHS Directive 2011/65/EU Compliant, RoHS, VDE
	Length 10mm
	Width 6mm

Datasheet - 6-1462037-7

The TE Connectivity Axicom IM46GR RF relay is a high-performance signal relay designed for DC applications. It features a bistable single-coil magnetic system with a contact voltage rating of 250 VAC and 220 VDC, it offers excellent insulation and robust performance in demanding environments. The relay is RoHS and ELV compliant, hermetically sealed, and suitable for reflow soldering, with a compact design ideal for PCB mounting.

2 Form C DPDT CO contact arrangement

Number of poles 2

Coil Voltage Rating 12 VDC

TE Connectivity IM46 Series Electromechanical Interface Relay, Surface, 12V dc Coil, DPDT
