TE Connectivity 8-1415067-1 Series Interface Relay Module, PCB, 12V dc Coil, SPST-NO
- RS Stock No.:
- 473-902
- Mfr. Part No.:
- 1-1414995-0
- Brand:
- TE Connectivity
Subtotal (1 pack of 3 units)*
£186.47
(exc. VAT)
£223.76
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 18 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £186.47 | £62.157 |
*price indicative
- RS Stock No.:
- 473-902
- Mfr. Part No.:
- 1-1414995-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Resistance | 43Ω | |
| Product Type | Interface Relay Module | |
| Coil Voltage | 12V dc | |
| Contact Configuration | SPST-NO | |
| Mount Type | PCB | |
| Series | 8-1415067-1 | |
| Terminal Type | Screw | |
| Switching Current | 50A | |
| Switching DC Voltage | 12V dc | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Silver Alloy | |
| Maximum Operating Temperature | 155°C | |
| Standards/Approvals | China RoHS 2 Directive MIIT Order No 32, EU RoHS Directive 2011/65/EU Compliant, EU REACH Regulation (EC) No. 1907/2006, EU ELV Directive 2000/53/EC Compliant, 2016 No Restricted Materials Above Threshold | |
| Width | 35.35mm | |
| Height | 42.5mm | |
| Length | 72mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Resistance 43Ω | ||
Product Type Interface Relay Module | ||
Coil Voltage 12V dc | ||
Contact Configuration SPST-NO | ||
Mount Type PCB | ||
Series 8-1415067-1 | ||
Terminal Type Screw | ||
Switching Current 50A | ||
Switching DC Voltage 12V dc | ||
Minimum Operating Temperature -40°C | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature 155°C | ||
Standards/Approvals China RoHS 2 Directive MIIT Order No 32, EU RoHS Directive 2011/65/EU Compliant, EU REACH Regulation (EC) No. 1907/2006, EU ELV Directive 2000/53/EC Compliant, 2016 No Restricted Materials Above Threshold | ||
Width 35.35mm | ||
Height 42.5mm | ||
Length 72mm | ||
- COO (Country of Origin):
- PT
The TE Connectivity High Current Relay HCR 200 is engineered for exceptional performance in demanding automotive applications. With a robust design suited to handle high current loads exceeding 50A, this relay offers reliability and efficiency under the stresses of operation. Featuring a 12 VDC coil voltage, it exhibits superior durability with a contact rating of 175 A at 85°C, ensuring it meets the rigorous standards required in automotive environments. Each unit is equipped with screw terminals for secure connections, while the monostable coil magnetic system guarantees swift operation. Additionally, the diode in parallel provides essential coil suppression, enhancing longevity and performance.
Designed for high current applications, ensuring reliable performance in challenging conditions
Screw terminal type facilitates easy installation and secure connections
Utilises a monostable coil system for quick and efficient operation
Includes coil suppression diode for enhanced reliability and longevity
Complies with crucial environmental directives such as EU RoHS and REACH
Low halogen content supports environmentally conscious product design
Offers a wide ambient temperature range to adapt to various conditions
