Festo, 450N, 8087822 24 V dc 10.47m/s
- RS Stock No.:
- 203-9818
- Distrelec Article No.:
- 301-86-959
- Mfr. Part No.:
- ERMS-32-180-ST-M-H1-PLK-AA
- Brand:
- Festo
Subtotal (1 unit)*
£1,113.52
(exc. VAT)
£1,336.22
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,113.52 |
*price indicative
- RS Stock No.:
- 203-9818
- Distrelec Article No.:
- 301-86-959
- Mfr. Part No.:
- ERMS-32-180-ST-M-H1-PLK-AA
- Brand:
- Festo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Festo | |
| Product Type | Electrical Linear Actuator | |
| Maximum Load | 450N | |
| Maximum Speed | 10.47m/s | |
| Series | ERMS | |
| Motor Technology | Stepper Motor | |
| Maximum Force | 450N | |
| Duty Cycle | 100% | |
| IP Rating | IP40 | |
| Minimum Operating Temperature | 0°C | |
| Maximum Operating Temperature | 50°C | |
| Weight | 2304g | |
| Standards/Approvals | CE mark | |
| Select all | ||
|---|---|---|
Brand Festo | ||
Product Type Electrical Linear Actuator | ||
Maximum Load 450N | ||
Maximum Speed 10.47m/s | ||
Series ERMS | ||
Motor Technology Stepper Motor | ||
Maximum Force 450N | ||
Duty Cycle 100% | ||
IP Rating IP40 | ||
Minimum Operating Temperature 0°C | ||
Maximum Operating Temperature 50°C | ||
Weight 2304g | ||
Standards/Approvals CE mark | ||
- COO (Country of Origin):
- DE
Festo ERMS Series Electric Linear Actuator, IP40, 1 Duty Cycle - ERMS-32-180-ST-M-H1-PLK-AA, Numeric Part Number:8087822
This electric linear actuator is intended for demanding applications in automation and industrial contexts. With a load capacity of 450N, it enables precise control and notable speed, making it suitable for a variety of tasks with effective and dependable performance.
Features & Benefits
• High-speed performance with a no-load speed of 10.47m/s
• Designed for continuous operation with a 100% duty cycle
• Configurable digital inputs and outputs for adaptable control
• Integrated motor encoder for precise position detection
• RoHS-compliant materials meet environmental standards
• IP40 rating protects against dust and debris
Applications
• Utilised in robotics for accurate movement and positioning
• Appropriate for material handling systems that require swift linear motion
• Employed in automated assembly lines for effective product manipulation
• Effective in medical devices where precision control is essential
What kind of power supply is suitable for operation?
The actuator functions on a nominal voltage of 24V DC and requires a connection that can support this voltage.
Can it be used in high-temperature environments?
The acceptable ambient temperature ranges from 0°C to 50°C, with power reduction needed above 30°C.
Is it compatible with different mounting positions?
Yes, it offers flexible mounting options via a female thread to accommodate various installation needs.
How often should maintenance be performed?
The actuator features lifetime lubrication, minimising the necessity for regular maintenance checks.
What type of motor is integrated into this actuator?
It is equipped with a stepper motor for precise control over movement and positioning.
