KNITTER-SWITCH 4 Way PCB DIP Switch 4PST, Flat Actuator
- RS Stock No.:
- 918-9950
- Mfr. Part No.:
- DBS 6004
- Brand:
- KNITTER-SWITCH
Bulk discount available
Subtotal (1 tube of 44 units)*
£48.664
(exc. VAT)
£58.388
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 44 unit(s) ready to ship
- Plus 44 unit(s) shipping from 10 December 2025
- Plus 88 unit(s) shipping from 07 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 44 - 44 | £1.106 | £48.66 |
| 88 - 176 | £1.079 | £47.48 |
| 220 - 396 | £1.018 | £44.79 |
| 440 - 836 | £0.94 | £41.36 |
| 880 + | £0.885 | £38.94 |
*price indicative
- RS Stock No.:
- 918-9950
- Mfr. Part No.:
- DBS 6004
- Brand:
- KNITTER-SWITCH
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KNITTER-SWITCH | |
| Number of Positions | 4 | |
| Mounting Type | PCB | |
| Contact Configuration | 4PST | |
| Contact Material | Gold over Nickel Plated | |
| Package Style | DIP | |
| Actuator Type | Flat | |
| Contact Current Rating | 100 (Non-Switching) mA, 25 (Switching) mA | |
| Mechanical Life | 5000Operations | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Operating Temperature Range | -40 → +85°C | |
| Voltage Rating | 24 V dc, 50V dc | |
| Dielectric Strength | 500V dc | |
Select all | ||
|---|---|---|
Brand KNITTER-SWITCH | ||
Number of Positions 4 | ||
Mounting Type PCB | ||
Contact Configuration 4PST | ||
Contact Material Gold over Nickel Plated | ||
Package Style DIP | ||
Actuator Type Flat | ||
Contact Current Rating 100 (Non-Switching) mA, 25 (Switching) mA | ||
Mechanical Life 5000Operations | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
Operating Temperature Range -40 → +85°C | ||
Voltage Rating 24 V dc, 50V dc | ||
Dielectric Strength 500V dc | ||
Knitter Switch DBS 60xx Series DIP Switches
The DBS 60xx series has been designed for PCB through-hole mounting with various contact configurations available. The flat actuators are mounted on top of the body and operated with a horizontal sliding motion.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications. They are sealed with a protective tape making them washable by aqueous detergents and isopropyl alcohol.
With a wide operating temperature range and a high mechanical life cycle they can be used in a variety of applications. They are sealed with a protective tape making them washable by aqueous detergents and isopropyl alcohol.
