Omron 4 Way PCB DIP Switch SPST, Flat Actuator, IP40
- RS Stock No.:
- 254-3073
- Mfr. Part No.:
- A6H-4102-P
- Brand:
- Omron
Available to back order for despatch when stock is available
Added
Price Each (In a Tube of 4000)
£2.107
(exc. VAT)
£2.528
(inc. VAT)
| Units | Per unit | Per Tube* |
| 4000 + | £2.107 | £8,428.00 |
| *price indicative | ||
- RS Stock No.:
- 254-3073
- Mfr. Part No.:
- A6H-4102-P
- Brand:
- Omron
Technical Reference
Legislation and Compliance
Product Details
The Omron slide dip switch is slide dip switches wIth ultra-low profile and half-pItch. It is half-pItch (1.27-mm) design reduces mounting space by 63%. (compared wIth conventional models)
Ambient operating temperature –20 to +70°C at 60% maximum (with no icing or condensation)
Ambient operating humidity 35% to 95% (at +5 to +35°C)
Insulation resistance 100 MΩ minimum (at 250 VDC with insulation tester)
Contact resistance (initial value) 200 mΩ maximum (initial value)
Dielectric strength between terminals 500 VAC for 1 min
Durability 1,000 operations min
Degree of protection IEC IP40
Ambient operating humidity 35% to 95% (at +5 to +35°C)
Insulation resistance 100 MΩ minimum (at 250 VDC with insulation tester)
Contact resistance (initial value) 200 mΩ maximum (initial value)
Dielectric strength between terminals 500 VAC for 1 min
Durability 1,000 operations min
Degree of protection IEC IP40
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 4 |
| Mounting Type | PCB |
| Contact Configuration | SPST |
| Actuator Type | Flat |
| Contact Current Rating | 25 mA |
| IP Rating | IP40 |
