CTS 4 Way Through Hole DIP Switch SPST, Side Actuator
- RS Stock No.:
- 177-4161
- Mfr. Part No.:
- 206-4RAST
- Brand:
- CTS
Discontinued
- RS Stock No.:
- 177-4161
- Mfr. Part No.:
- 206-4RAST
- Brand:
- CTS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CTS | |
| Number of Positions | 4 | |
| Mounting Type | Through Hole | |
| Contact Configuration | SPST | |
| Package Style | DIP | |
| Actuator Type | Side | |
| Contact Current Rating | 100 (Non Switching) mA, 50 (Switching) mA | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -55°C | |
| Operating Temperature Range | -55 → +85°C | |
| Voltage Rating | 24 V dc, 50 (Non Switching) V dc | |
| Dielectric Strength | 500V ac | |
| Select all | ||
|---|---|---|
Brand CTS | ||
Number of Positions 4 | ||
Mounting Type Through Hole | ||
Contact Configuration SPST | ||
Package Style DIP | ||
Actuator Type Side | ||
Contact Current Rating 100 (Non Switching) mA, 50 (Switching) mA | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -55°C | ||
Operating Temperature Range -55 → +85°C | ||
Voltage Rating 24 V dc, 50 (Non Switching) V dc | ||
Dielectric Strength 500V ac | ||
- COO (Country of Origin):
- TW
CTS slide DIP Switch versions are available in a broad range of low profile, half pitch (.05 inch), standard pitch (.1 inch), through hole, and surface mount options. We offer top, right angle, or side actuation styles. Additionally, our unique design & construction allows for superior ESD protection in many of our DIP switch products.
Optimized Mechanical Features
Designed for panel applications Saves cost of right angle socket
Multiple circuit configurations available
Standard 2.54mm (.100") x 2.54mm (.100") centers, uses minimum PCB real estate
Available with low profile, standard, or extended actuators for SPST circuitry
Optimized Contact System
Contact wiping action on make and break
Integral terminal and contact locked into high temperature plastic base
Electrostatic discharge shield rated to 22 KV
Materials
Series 206RA, gold plated contacts for long-term contact corrosion resistance
Series 208RA, tin plated contacts
Designed for panel applications Saves cost of right angle socket
Multiple circuit configurations available
Standard 2.54mm (.100") x 2.54mm (.100") centers, uses minimum PCB real estate
Available with low profile, standard, or extended actuators for SPST circuitry
Optimized Contact System
Contact wiping action on make and break
Integral terminal and contact locked into high temperature plastic base
Electrostatic discharge shield rated to 22 KV
Materials
Series 206RA, gold plated contacts for long-term contact corrosion resistance
Series 208RA, tin plated contacts
