Omron 1 Way Surface Mount DIP Switch SPST, Flat Actuator, IP00
- RS Stock No.:
- 174-8166
- Mfr. Part No.:
- B3FS-1012P
- Brand:
- Omron
Discontinued
- RS Stock No.:
- 174-8166
- Mfr. Part No.:
- B3FS-1012P
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Number of Positions | 1 | |
| Mounting Type | Surface Mount | |
| Contact Configuration | SPST | |
| Contact Material | Silver | |
| Package Style | SMT | |
| Actuator Type | Flat | |
| Contact Current Rating | 1 → 50 mA | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -25°C | |
| Operating Temperature Range | -25 → +70°C | |
| IP Rating | IP00 | |
| Voltage Rating | 3 → 24V dc | |
| Dielectric Strength | 250V ac | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Number of Positions 1 | ||
Mounting Type Surface Mount | ||
Contact Configuration SPST | ||
Contact Material Silver | ||
Package Style SMT | ||
Actuator Type Flat | ||
Contact Current Rating 1 → 50 mA | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -25°C | ||
Operating Temperature Range -25 → +70°C | ||
IP Rating IP00 | ||
Voltage Rating 3 → 24V dc | ||
Dielectric Strength 250V ac | ||
- COO (Country of Origin):
- CN
6 x 6-mm Surface-mounting Switches for High-density Mounting. Available on Embossed Tape
Provide a sharp click and high durability.
Tape packing style also available.
B32-series Key Tops mount to models with projected plungers
Tape packing style also available.
B32-series Key Tops mount to models with projected plungers
