Siemens 4AV DIN Rail Power Supply, 415V ac ac Input, 24V dc dc Output, 10A Output
- RS Stock No.:
- 213-1316
- Mfr. Part No.:
- 4AV2400-2EB00-0A
- Brand:
- Siemens
Subtotal (1 unit)*
£473.69
(exc. VAT)
£568.43
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £473.69 |
*price indicative
- RS Stock No.:
- 213-1316
- Mfr. Part No.:
- 4AV2400-2EB00-0A
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Siemens | |
Series | 4AV | |
Type | Power Supply | |
AC Input Voltage | 415V ac | |
Electrical Phase | 1 | |
AC or DC Input Voltage | ac | |
Input Voltage | 415V ac | |
AC or DC Output Voltage | dc | |
Output Voltage | 24V dc | |
Output Current | 10A | |
Dimensions | 170 x 120 x 128mm | |
Height | 170mm | |
Width | 120mm | |
Depth | 128mm | |
Mounting Type | DIN Rail Mount | |
Standards Met | CE | |
Maximum Temperature | +60°C | |
Select all | ||
---|---|---|
Brand Siemens | ||
Series 4AV | ||
Type Power Supply | ||
AC Input Voltage 415V ac | ||
Electrical Phase 1 | ||
AC or DC Input Voltage ac | ||
Input Voltage 415V ac | ||
AC or DC Output Voltage dc | ||
Output Voltage 24V dc | ||
Output Current 10A | ||
Dimensions 170 x 120 x 128mm | ||
Height 170mm | ||
Width 120mm | ||
Depth 128mm | ||
Mounting Type DIN Rail Mount | ||
Standards Met CE | ||
Maximum Temperature +60°C | ||
- COO (Country of Origin):
- CZ
Siemens 4AV Series DIN Rail Power Supply, 415V AC Input Voltage, 24V DC Output Voltage - 4AV2400-2EB00-0A
This DIN Rail Power Supply from Siemens is designed for industrial applications, featuring an AC input voltage of 415V and a DC output voltage of 24V. Compactly sized at 170 x 120 x 128mm, this power supply ensures efficient energy management while fitting seamlessly into automated systems.
Features & Benefits
• Provides a robust 10A output current for reliable performance
• Utilises screw-type terminals for secure electrical connections
• Complies with CE certification standards for safety
• Designed for a maximum temperature of +60°C to withstand demanding environments
• Features a maximum relative ripple of 5% for stable output voltage
• Operates within an input voltage range of 193.5V to 439.9V
• Utilises screw-type terminals for secure electrical connections
• Complies with CE certification standards for safety
• Designed for a maximum temperature of +60°C to withstand demanding environments
• Features a maximum relative ripple of 5% for stable output voltage
• Operates within an input voltage range of 193.5V to 439.9V
Applications
• Used in control panels for automation systems
• Suitable for powering sensors and actuators in machinery
• Ideal for in the electrical and mechanical sectors
• Employed in installations requiring a stable 24V DC supply
• Suitable for powering sensors and actuators in machinery
• Ideal for in the electrical and mechanical sectors
• Employed in installations requiring a stable 24V DC supply
What input voltage range can this power supply handle?
It can accommodate an input voltage range from 193.5V to 439.9V, making it flexible for various electrical requirements in industrial settings.
What protections are available for this power supply?
It features varistor protective wiring, ensuring safety against transient voltage spikes.
How is the unit mounted in electrical panels?
The device uses DIN Rail Mounting, enabling easy integration into existing industrial systems.
What sort of electrical connection is provided at the output?
It includes screw-type terminals, which allow for secure connections to other components in the circuit.
What is the rated ambient temperature for operation?
The power supply is rated for ambient temperatures up to +60°C, ensuring reliable performance even in high-temperature environments.
