RS PRO DIN Rail Power Supply, 90 → 264V ac ac, dc Input, 48V dc dc Output, 10A Output, 480W
- RS Stock No.:
- 308-417
- Brand:
- RS PRO
Subtotal (1 unit)*
£252.29
(exc. VAT)
£302.75
(inc. VAT)
FREE delivery for orders over £50.00
- 3 unit(s) ready to ship
- Plus 999,999,996 unit(s) shipping from 13 February 2026
Units | Per unit |
---|---|
1 + | £252.29 |
*price indicative
- RS Stock No.:
- 308-417
- Brand:
- RS PRO
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
DC Input Voltage | 127 → 370V dc | |
AC Input Voltage | 90 → 264V ac | |
Type | DIN Rail Power Supply | |
Electrical Phase | Single | |
Number of Outputs | 1 | |
AC or DC Input Voltage | ac, dc | |
Input Voltage | 90 → 264V ac | |
AC or DC Output Voltage | dc | |
Output Voltage | 48V dc | |
Output Current | 10A | |
Dimensions | 85.5 x 125 x 129mm | |
Height | 129mm | |
Depth | 85.5mm | |
Width | 125mm | |
Load Regulation | ±1% | |
Maximum Temperature | 70°C | |
Ripple And Noise | 160mV | |
Efficiency | 92% | |
Minimum Temperature | -20°C | |
Standards Met | BS EN/EN55032, BS EN/EN61000-3-2-3, BS EN/EN55024, BS EN/EN61000-6-2U, BS EN/EN50082-2, UL508/EN62368-1/BS62368-1 | |
Mounting Type | DIN Rail Mount | |
MTBF | 200000h | |
Special Features | High Efficiency, Protection: OVP, OLP, SCP | |
Select all | ||
---|---|---|
Brand RS PRO | ||
DC Input Voltage 127 → 370V dc | ||
AC Input Voltage 90 → 264V ac | ||
Type DIN Rail Power Supply | ||
Electrical Phase Single | ||
Number of Outputs 1 | ||
AC or DC Input Voltage ac, dc | ||
Input Voltage 90 → 264V ac | ||
AC or DC Output Voltage dc | ||
Output Voltage 48V dc | ||
Output Current 10A | ||
Dimensions 85.5 x 125 x 129mm | ||
Height 129mm | ||
Depth 85.5mm | ||
Width 125mm | ||
Load Regulation ±1% | ||
Maximum Temperature 70°C | ||
Ripple And Noise 160mV | ||
Efficiency 92% | ||
Minimum Temperature -20°C | ||
Standards Met BS EN/EN55032, BS EN/EN61000-3-2-3, BS EN/EN55024, BS EN/EN61000-6-2U, BS EN/EN50082-2, UL508/EN62368-1/BS62368-1 | ||
Mounting Type DIN Rail Mount | ||
MTBF 200000h | ||
Special Features High Efficiency, Protection: OVP, OLP, SCP | ||
- COO (Country of Origin):
- CN
RS PRO DIN Rail Power Supply, 480W
Features and Benefits
DC Output Adjustable: Allows for flexibility in output voltage settings
Output Voltages: 24-48V DC: Supports various application needs
Meets the Latest Safety Standards and Approvals: Ensures compliance with UL508, BS/EN62368-1
High Efficiency: Reduces energy consumption and operational costs
Protection: OVP, OLP, SCP: Safeguards against over-voltage, over-load, and short-circuit conditions
Applications
Additional Information
Why RS PRO?
