NCID9211R2 onsemi, 2-Channel Digital Isolator 50 Mbps, 5 kV, 5.5 V, 16-Pin SOIC
- RS Stock No.:
- 205-2472
- Mfr. Part No.:
- NCID9211R2
- Brand:
- onsemi
Bulk discount available
Subtotal (1 unit)*
£4.66
(exc. VAT)
£5.59
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 650 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £4.66 |
| 10 - 99 | £4.02 |
| 100 - 499 | £3.48 |
| 500 + | £3.06 |
*price indicative
- RS Stock No.:
- 205-2472
- Mfr. Part No.:
- NCID9211R2
- Brand:
- onsemi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | onsemi | |
| Number of Channels | 2 | |
| Product Type | Digital Isolator | |
| Maximum Data Rate | 50Mbps | |
| Package Type | SOIC | |
| Power Dissipation | 210mW | |
| Data Rate | 50Mbps | |
| Maximum Forward Voltage | 5.5V | |
| Propagation Delay Time | 25ns | |
| Maximum Input Current | 145mA | |
| Isolation Voltage | 5kV | |
| Rise Time | 1.1ns | |
| Number of Pins | 16 | |
| Mount Type | Surface | |
| Maximum Operating Temperature | 125°C | |
| Minimum Operating Temperature | -40°C | |
| Series | NCID | |
| Standards/Approvals | DIN, EN, UL | |
| Length | 10.3mm | |
| Depth | 3mm | |
| Automotive Standard | AEC-Q100 | |
| Package Style | SOIC | |
| Select all | ||
|---|---|---|
Brand onsemi | ||
Number of Channels 2 | ||
Product Type Digital Isolator | ||
Maximum Data Rate 50Mbps | ||
Package Type SOIC | ||
Power Dissipation 210mW | ||
Data Rate 50Mbps | ||
Maximum Forward Voltage 5.5V | ||
Propagation Delay Time 25ns | ||
Maximum Input Current 145mA | ||
Isolation Voltage 5kV | ||
Rise Time 1.1ns | ||
Number of Pins 16 | ||
Mount Type Surface | ||
Maximum Operating Temperature 125°C | ||
Minimum Operating Temperature -40°C | ||
Series NCID | ||
Standards/Approvals DIN, EN, UL | ||
Length 10.3mm | ||
Depth 3mm | ||
Automotive Standard AEC-Q100 | ||
Package Style SOIC | ||
The ON Semiconductor galvanic ally isolated full duplex, bi-directional, high-speed dual-channel digital isolator supports isolated communications thereby allowing digital signals to communicate between systems without conducting ground loops or hazardous voltages. It utilizes galvanic off-chip capacitor isolation technology and optimized IC design to achieve high insulation and high noise immunity, characterized by high common mode rejection and power supply rejection specifications.
Specifications guaranteed over 2.5V to 5.5V supply voltage
Over temperature detection
Output enable function (primary and secondary side)
Maximum working insulation voltage: 2000Vpeak
DTI (distance through insulation): = 0.5mm
8mm creep age and clearance distance to achieve reliable high voltage insulation
Package type is SOIC16 W
