onsemi, 2-Channel Digital Isolator 50 Mbps, 5 kV, 5.5 V, 16-Pin SOIC
- RS Stock No.:
- 205-2471
- Mfr. Part No.:
- NCID9211R2
- Brand:
- onsemi
Subtotal (1 reel of 750 units)*
£1,806.00
(exc. VAT)
£2,167.50
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 750 + | £2.408 | £1,806.00 |
*price indicative
- RS Stock No.:
- 205-2471
- Mfr. Part No.:
- NCID9211R2
- Brand:
- onsemi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | onsemi | |
| Number of Channels | 2 | |
| Maximum Data Rate | 50Mbps | |
| Product Type | Digital Isolator | |
| Package Type | SOIC | |
| Power Dissipation | 210mW | |
| Maximum Forward Voltage | 5.5V | |
| Data Rate | 50Mbps | |
| Maximum Input Current | 145mA | |
| Propagation Delay Time | 25ns | |
| Isolation Voltage | 5kV | |
| Rise Time | 1.1ns | |
| Number of Pins | 16 | |
| Mount Type | Surface | |
| Maximum Operating Temperature | 125°C | |
| Minimum Operating Temperature | -40°C | |
| Length | 10.3mm | |
| Depth | 3mm | |
| Series | NCID | |
| Standards/Approvals | DIN, EN, UL | |
| Package Style | SOIC | |
| Automotive Standard | AEC-Q100 | |
| Select all | ||
|---|---|---|
Brand onsemi | ||
Number of Channels 2 | ||
Maximum Data Rate 50Mbps | ||
Product Type Digital Isolator | ||
Package Type SOIC | ||
Power Dissipation 210mW | ||
Maximum Forward Voltage 5.5V | ||
Data Rate 50Mbps | ||
Maximum Input Current 145mA | ||
Propagation Delay Time 25ns | ||
Isolation Voltage 5kV | ||
Rise Time 1.1ns | ||
Number of Pins 16 | ||
Mount Type Surface | ||
Maximum Operating Temperature 125°C | ||
Minimum Operating Temperature -40°C | ||
Length 10.3mm | ||
Depth 3mm | ||
Series NCID | ||
Standards/Approvals DIN, EN, UL | ||
Package Style SOIC | ||
Automotive Standard AEC-Q100 | ||
The ON Semiconductor galvanic ally isolated full duplex, bi-directional, high-speed dual-channel digital isolator supports isolated communications thereby allowing digital signals to communicate between systems without conducting ground loops or hazardous voltages. It utilizes galvanic off-chip capacitor isolation technology and optimized IC design to achieve high insulation and high noise immunity, characterized by high common mode rejection and power supply rejection specifications.
Specifications guaranteed over 2.5V to 5.5V supply voltage
Over temperature detection
Output enable function (primary and secondary side)
Maximum working insulation voltage: 2000Vpeak
DTI (distance through insulation): = 0.5mm
8mm creep age and clearance distance to achieve reliable high voltage insulation
Package type is SOIC16 W
