TDK-Lambda CCG 30 DC-DC Converter, 3.3V dc/ 7A Output, 9 → 36 V dc Input, 23.1W, Through Hole, +85°C Max Temp
- RS Stock No.:
- 899-8491
- Distrelec Article No.:
- 301-45-574
- Mfr. Part No.:
- CCG30-24-03S
- Brand:
- TDK-Lambda
Bulk discount available
Subtotal (1 unit)*
£33.92
(exc. VAT)
£40.70
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £33.92 |
| 5 - 9 | £32.90 |
| 10 - 24 | £31.89 |
| 25 - 49 | £30.87 |
| 50 + | £29.85 |
*price indicative
- RS Stock No.:
- 899-8491
- Distrelec Article No.:
- 301-45-574
- Mfr. Part No.:
- CCG30-24-03S
- Brand:
- TDK-Lambda
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK-Lambda | |
| Output Voltage | 3.3V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Power Rating | 23.1W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 7A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | DIP | |
| Isolation Voltage | 1.5kV dc | |
| Length | 25.4mm | |
| Depth | 9.9mm | |
| Width | 25.4mm | |
| Series | CCG 30 | |
| Load Regulation | 13.2mV | |
| Priced to Clear | Yes | |
| Maximum Temperature | +85°C | |
| Standards Met | CE Mark, CSA 60950-1, EN 60950-1, L 60950-1, RoHS Compliant | |
| Efficiency | 86% | |
| Minimum Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TDK-Lambda | ||
Output Voltage 3.3V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 23.1W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 7A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package DIP | ||
Isolation Voltage 1.5kV dc | ||
Length 25.4mm | ||
Depth 9.9mm | ||
Width 25.4mm | ||
Series CCG 30 | ||
Load Regulation 13.2mV | ||
Priced to Clear Yes | ||
Maximum Temperature +85°C | ||
Standards Met CE Mark, CSA 60950-1, EN 60950-1, L 60950-1, RoHS Compliant | ||
Efficiency 86% | ||
Minimum Temperature -40°C | ||
