TRACOPOWER THL 10WI DC/DC Converter, 18V dc, 75 V dc/ 1 A, 75V dc Input, 18V Input 10 W, Through Hole, 85 °C Max Temp
- RS Stock No.:
- 733-1853
- Mfr. Part No.:
- THL 10-4821WI
- Brand:
- TRACOPOWER
Subtotal (1 unit)*
£29.45
(exc. VAT)
£35.34
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £29.45 |
*price indicative
- RS Stock No.:
- 733-1853
- Mfr. Part No.:
- THL 10-4821WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 18, 75V dc | |
| Maximum Input Voltage | 75V dc | |
| Minimum Input Voltage | 18V | |
| Output Current 1 | 1A | |
| Mount Type | Through Hole | |
| Input Ratio | 1:6 | |
| Number of Outputs | 2 | |
| MTBF | 300000h | |
| Ripple and Noise | 60mV Pk-Pk | |
| Number of Pins | 5 | |
| Isolation Voltage | 1.5kV dc | |
| Maximum Output Power | 10W | |
| Length | 25.4mm | |
| Series | THL 10WI | |
| Depth | 10.2mm | |
| Width | 25.4mm | |
| Standards/Approvals | RoHS | |
| Weight | 15g | |
| Efficiency | 84% | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type DC/DC Converter | ||
Output Voltage 1 18, 75V dc | ||
Maximum Input Voltage 75V dc | ||
Minimum Input Voltage 18V | ||
Output Current 1 1A | ||
Mount Type Through Hole | ||
Input Ratio 1:6 | ||
Number of Outputs 2 | ||
MTBF 300000h | ||
Ripple and Noise 60mV Pk-Pk | ||
Number of Pins 5 | ||
Isolation Voltage 1.5kV dc | ||
Maximum Output Power 10W | ||
Length 25.4mm | ||
Series THL 10WI | ||
Depth 10.2mm | ||
Width 25.4mm | ||
Standards/Approvals RoHS | ||
Weight 15g | ||
Efficiency 84% | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
Traco 10W Regulated Isolated DC-DC Converter - THL 10WI Serie
10W single/dual output DC/DC converters with a compact 1" x 1" design and industrial standard pinout. These DC/ DC converters have a wide 4:1 input voltage range and EN 55022 Class A compliant input filter. Typical applications for these DC/DC converters include instrumentation and distributed power architectures in communication and industrial electronics.
Compact 1" x 1" package with industry standard pinout
Ultrawide 4:1 input voltage ranges
Shielded metal case with isolated baseplate
Remote On/Off control
Short circuit and overvoltage protection
EMC compliance to EN 55022 class A, FCC part 15, level A without external components
Note
MTBF to MIL-HDBK-217F (25°C)
Power derates 2.5% / K above + 60°C
Power derates 2.5% / K above + 60°C
Standards
UL 60950-1, IEC/EN 60950-1
