Recom RPMGS-20 DC/DC Converter, 5V dc/ 20 A, 75V dc Input, 18V, PCB, 120 °C Max Temp -40 °C Min Temp, Tray
- RS Stock No.:
- 274-5497
- Mfr. Part No.:
- RPMGS5.0-20
- Brand:
- Recom
Bulk discount available
Subtotal (1 tube of 15 units)*
£697.79
(exc. VAT)
£837.35
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 07 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 9 | £697.79 | £46.519 |
| 10 + | £632.89 | £42.193 |
*price indicative
- RS Stock No.:
- 274-5497
- Mfr. Part No.:
- RPMGS5.0-20
- Brand:
- Recom
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Recom | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 5V dc | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 75V dc | |
| Mount Type | PCB | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 3.3 to 8 V dc (for RPMGS5.0-20), 8 to 24 V dc (for RPMGS12-20) | |
| Output Current 1 | 20A | |
| Package Type | Tray | |
| Maximum Output Power | 0.75W | |
| Standards/Approvals | RoHS, REACH | |
| Weight | 29g | |
| Width | 34.04mm | |
| Length | 36.83mm | |
| Series | RPMGS-20 | |
| Maximum Operating Temperature | 120°C | |
| Efficiency | 98% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Recom | ||
Product Type DC/DC Converter | ||
Output Voltage 1 5V dc | ||
Minimum Input Voltage 18V | ||
Maximum Input Voltage 75V dc | ||
Mount Type PCB | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 3.3 to 8 V dc (for RPMGS5.0-20), 8 to 24 V dc (for RPMGS12-20) | ||
Output Current 1 20A | ||
Package Type Tray | ||
Maximum Output Power 0.75W | ||
Standards/Approvals RoHS, REACH | ||
Weight 29g | ||
Width 34.04mm | ||
Length 36.83mm | ||
Series RPMGS-20 | ||
Maximum Operating Temperature 120°C | ||
Efficiency 98% | ||
Minimum Operating Temperature -40°C | ||
The Recom DC/DC converter is a non-isolated device in a standard industrial quarter brick format. The high efficiency and thermal design of the product means that minimal derating is required, even at high temperatures. The trimmable output and remote con
Highly efficient
Remote sense Ability
