TRACOPOWER TMR 12WI DC-DC Converter, 3.3V dc/ 2.4A Output, 18 → 75 V dc Input, 12W, PCB Mount, +85°C Max Temp
- RS Stock No.:
- 251-7296
- Mfr. Part No.:
- TMR 12-4811WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£32.60
(exc. VAT)
£39.12
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £32.60 |
5 - 9 | £31.62 |
10 - 24 | £30.64 |
25 - 49 | £29.34 |
50 + | £28.04 |
*price indicative
- RS Stock No.:
- 251-7296
- Mfr. Part No.:
- TMR 12-4811WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 3.3V dc | |
Input Voltage Range | 18 → 75 V dc | |
Power Rating | 12W | |
Input Voltage Nominal | 48 V DC | |
Output Current | 2.4A | |
Mounting Type | PCB Mount | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | SIP 8 | |
Isolation Voltage | 1.6kV dc | |
Depth | 12mm | |
Width | 9.6mm | |
Length | 22mm | |
Series | TMR 12WI | |
Railway Approved | No | |
Load Regulation | 0.5% | |
Maximum Temperature | +85°C | |
Medical Approved | No | |
Standards Met | RoHS | |
Efficiency | 89% | |
Minimum Temperature | -40°C | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 3.3V dc | ||
Input Voltage Range 18 → 75 V dc | ||
Power Rating 12W | ||
Input Voltage Nominal 48 V DC | ||
Output Current 2.4A | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SIP 8 | ||
Isolation Voltage 1.6kV dc | ||
Depth 12mm | ||
Width 9.6mm | ||
Length 22mm | ||
Series TMR 12WI | ||
Railway Approved No | ||
Load Regulation 0.5% | ||
Maximum Temperature +85°C | ||
Medical Approved No | ||
Standards Met RoHS | ||
Efficiency 89% | ||
Minimum Temperature -40°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
TRACOPOWER TMR 12WI Series DC-DC Converter, 18 to 75V DC Input Voltage Range, 12W Power Rating - TMR 12-4811WI
This ultra-compact DC-DC converter from the TMR 12WI series operates efficiently within an input range of 18 to 75V DC, delivering a regulated output of 5.1V DC at up to 2400mA. With an efficiency of up to 89%, it ensures minimal energy loss. It features comprehensive I/O isolation of 1600V DC for enhanced safety, making it ideal for critical applications.
Features & Benefits
• High efficiency (up to 89%) results in low thermal loss
• Wide input voltage range enhances application versatility
• Continuous short-circuit protection ensures reliability
• RoHS compliant design meets environmental standards
• Wide input voltage range enhances application versatility
• Continuous short-circuit protection ensures reliability
• RoHS compliant design meets environmental standards
Applications
• Suitable for communication equipment requiring a stable power supply
• Ideal for automation systems needing efficient power conversion
• Ideal for automation systems needing efficient power conversion
Is it suitable for high-temperature environments?
Yes, it operates effectively from -40 to +85°C.
Will it provide stable output under varying loads?
Yes, it features load regulation of 0.5%.
Can the converter be remotely controlled?
Yes, it supports remote ON/OFF functionality with a control range of 0 to 1.2V DC for ON and 3 to 12V DC for OFF.
Is it compliant with safety regulations?
Yes, it meets IEC 62368-1 and UL 62368-1 standards.
