TRACOPOWER THN 30WIR Isolated DC-DC Converter, 12V dc/ 2500 mA, 75V dc Input, 18V Input 30 W, PCB, 65 °C Max Temp -40 °C

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£58.51

(exc. VAT)

£70.21

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 13 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£58.51
5 - 9£56.76
10 - 24£55.00
25 - 49£52.66
50 +£50.32

*price indicative

RS Stock No.:
249-7360
Distrelec Article No.:
302-64-344
Mfr. Part No.:
THN 30-4812WIR
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage 1

12V dc

Product Type

Isolated DC-DC Converter

Minimum Input Voltage

18V

Maximum Input Voltage

75V dc

Output Current 1

2500mA

Mount Type

PCB

Input Ratio

4:1

Number of Outputs

1

MTBF

420800h

Output Voltage Adjustment Range

10.8/13.2 V dc

Number of Pins

6

Isolation Voltage

2.25kV dc

Package Type

Metal

Maximum Output Power

30W

Length

25.4mm

Width

25.4mm

Depth

9.9mm

Series

THN 30WIR

Standards/Approvals

RoHS

Maximum Operating Temperature

65°C

Efficiency

90%

Minimum Operating Temperature

-40°C

RoHS Status: Exempt

COO (Country of Origin):
TW

TRACOPOWER THN 30WIR Series Isolated DC-DC Converter, 18 to 75V DC Input Voltage Range, 30W Power Rating - THN 30-4812WIR


This encapsulated DC/DC converter from the THN 30WIR series delivers 30 Watts in a compact 1"x1" metal package. It features a wide input voltage range of 18-75 VDC and offers a high efficiency of up to 90%. With an operating temperature range from -40 to +65°C, it ensures reliable performance in demanding environments.

Features & Benefits


• High voltage isolation with 2250V DC for safety

• Adjustable output voltage ranging from 10.8V to 13.2V

• Built-in protection features enhance operational safety

Applications


• Suitable for railway applications requiring power conversion

• Used in automation systems necessitating isolated power sources

• Ideal for electronics needing a stable voltage supply

• Utilised in harsh environments with extreme temperature ranges

• Designed for integration within PCB for versatility

What is the isolation voltage for this converter?


It provides 3000 VDC input to output isolation.

How can the output voltage be adjusted?


Output voltage can be tweaked using an external trim resistor.
