TRACOPOWER THR 3WI Isolated DC-DC Converter, 15V dc/ 200 mA, 36V dc Input, 9V Input 10 W, Through Hole, 92 °C Max Temp

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£21.73

(exc. VAT)

£26.08

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 17 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£21.73
5 - 9£21.08
10 - 24£20.42
25 - 49£19.55
50 +£18.68

*price indicative

RS Stock No.:
249-5511
Distrelec Article No.:
302-64-396
Mfr. Part No.:
THR 3-2413WI
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage 1

15V dc

Product Type

Isolated DC-DC Converter

Maximum Input Voltage

36V dc

Minimum Input Voltage

9V

Output Current 1

200mA

Mount Type

Through Hole

Input Ratio

4:1

MTBF

3360000h

Number of Outputs

5

Isolation Voltage

3kV dc

Number of Pins

7

Package Type

DIP-24

Maximum Output Power

10W

Series

THR 3WI

Depth

12mm

Standards/Approvals

No

Length

31.8mm

Maximum Operating Temperature

92°C

Minimum Operating Temperature

-40°C

Efficiency

85%

RoHS Status: Exempt

COO (Country of Origin):
TW
The TRACOPOWER the THR 3WI is 3 Watt DC/DC converters series with reinforced isolation (3000 VAC). These regulated DC/DC converters come in either a DIP-24 package and also feature increased resistance against shock and vibration according to EN 61373. The THR 3WI offers an internal input filter to comply with EN 55032 class A

Reinforced I/O-isolation 3000 VAC

Shock and vibration resistance according to EN 61373

Wide 4:1 input voltage range: 9-36, 18-75, 40-160 VDC

Operating temperature range -40 to +92°C

Internal EN 55032 class A filter

High efficiency up to 85%

Protection against overload, overvoltage and short circuit

3-year product warranty
