XP Power HRL30 DC-DC Converter, 0 → 2000V dc/ 15mA Output, 22 → 30 V dc Input, 30W, Through Hole, +70°C

The XP Power, HRL30 series, is a miniature 30W regulated high voltage DC-DC converter product line providing voltages up to 6kV. HRL30 offers both voltage and current mode controls and monitors. This product deploys a proprietary design which delivers accurate high voltage at higher efficiency with low EMI. This product has constant voltage and constant current operation with automatic crossover to current limiting mode preventing the delivered current from exceeding the programmed current level. It has digital compatible voltage and current monitors and controls to make it a convenient product for a wide range of high voltage applications.

Output voltage & current regulated
0 to 100% programmable output & current
Voltage & current monitor outputs
Operating temperature: -40°C to +70°C
Short circuit, Arc, and overload protections
On-board +5V reference
Efficiency >80%
Low ripple <0.05%
Premier thermal performance
UL 60950 and 62368 approved
