TRACOPOWER THB 3 DC/DC Converter, 12V dc/ 250 mA, 75V dc Input, 36V Input 3 W, Through Hole, 75 °C Max Temp -40 °C Min
- RS Stock No.:
- 200-8428
- Mfr. Part No.:
- THB 3-4812
- Brand:
- TRACOPOWER
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£336.49
(exc. VAT)
£403.79
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 11 January 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £336.49 | £33.649 |
| 5 - 9 | £326.40 | £32.64 |
| 10 - 24 | £316.30 | £31.63 |
| 25 - 49 | £302.84 | £30.284 |
| 50 + | £289.39 | £28.939 |
*price indicative
- RS Stock No.:
- 200-8428
- Mfr. Part No.:
- THB 3-4812
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 75V dc | |
| Minimum Input Voltage | 36V | |
| Output Current 1 | 250mA | |
| Mount Type | Through Hole | |
| MTBF | 1000000h | |
| Number of Outputs | 1 | |
| Ripple and Noise | 50mV Pk-Pk | |
| Number of Pins | 7 | |
| Isolation Voltage | 4.8kV dc | |
| Package Type | DIP | |
| Maximum Output Power | 3W | |
| Depth | 10.5mm | |
| Width | 20.3mm | |
| Standards/Approvals | No | |
| Length | 31.8mm | |
| Weight | 12.4g | |
| Series | THB 3 | |
| Maximum Operating Temperature | 75°C | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 0.83% | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 75V dc | ||
Minimum Input Voltage 36V | ||
Output Current 1 250mA | ||
Mount Type Through Hole | ||
MTBF 1000000h | ||
Number of Outputs 1 | ||
Ripple and Noise 50mV Pk-Pk | ||
Number of Pins 7 | ||
Isolation Voltage 4.8kV dc | ||
Package Type DIP | ||
Maximum Output Power 3W | ||
Depth 10.5mm | ||
Width 20.3mm | ||
Standards/Approvals No | ||
Length 31.8mm | ||
Weight 12.4g | ||
Series THB 3 | ||
Maximum Operating Temperature 75°C | ||
Minimum Operating Temperature -40°C | ||
Efficiency 0.83% | ||
- COO (Country of Origin):
- TW
The Traco THB 3-4812 is a high performance, regulated DC/DC converter with a wide 2:1 input voltage range make this product the best choice for many demanding applications like transportation systems, industrial controls, medical equipment, instrumentations, everywhere where high basic-, supplementary- or reinforced insulation is required to meet requested safety standards.
Comes in a DIP-24 plastic package
2x MOOP Medical safety according to AAMI/ANSI ES 60601-1:2005(R) and IEC/EN 60601-1 3rd edition
Operating temperature range -40°C to 85°C
