Recom RPMH-0.5 DC/DC Converter, 6V dc, 65 V dc/ 500 mA, 65V dc Input, 6V, Surface, 105 °C Max Temp -40 °C Min Temp, LGA

RS Stock No.:: 199-5097
Mfr. Part No.:: RPMH5.0-0.5-CT
Brand:: Recom

Recom RPMH-0.5 DC/DC Converter, 6V dc, 65 V dc/ 500 mA, 65V dc Input, 6V, Surface, 105 °C Max Temp -40 °C Min Temp, LGA

Subtotal (1 tube of 30 units)*

£154.98

(exc. VAT)

£185.98

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

1 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Tube(s)	Per Tube	Per unit*
1 +	£154.98	£5.166

*price indicative

RS Stock No.:: 199-5097
Mfr. Part No.:: RPMH5.0-0.5-CT
Brand:: Recom

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Recom
	Product Type	DC/DC Converter
	Output Voltage 1	6, 65V dc
	Maximum Input Voltage	65V dc
	Minimum Input Voltage	6V
	Mount Type	Surface
	Number of Outputs	5
	Output Voltage Adjustment Range	4 to 5.5 V dc
	Output Current 1	500mA
	Package Type	LGA
	Length	12.19mm
	Standards/Approvals	No
	Width	12.19mm
	Series	RPMH-0.5
	Depth	3.75mm
	Maximum Operating Temperature	105°C
	Minimum Operating Temperature	-40°C
	Efficiency	77%

	Select all
	Brand Recom
	Product Type DC/DC Converter
	Output Voltage 1 6, 65V dc
	Maximum Input Voltage 65V dc
	Minimum Input Voltage 6V
	Mount Type Surface
	Number of Outputs 5
	Output Voltage Adjustment Range 4 to 5.5 V dc
	Output Current 1 500mA
	Package Type LGA
	Length 12.19mm
	Standards/Approvals No
	Width 12.19mm
	Series RPMH-0.5
	Depth 3.75mm
	Maximum Operating Temperature 105°C
	Minimum Operating Temperature -40°C
	Efficiency 77%

COO (Country of Origin):: SK

RECOM DC-DC Converter, Adjustable Output, 4 to 5.5V DC Voltage Adjustment Range - RPMH-0.5 Series - RPMH5.0-0.5-CT

Balance the power feed to your electric circuit using this DC-DC converter from RECOM. It steps down a broad input voltage range between 6 and 65V DC to output a smooth 5V DC. For flexibility, you can tweak the output to achieve a tailored supply between 4 and 5.5V DC. Thanks to an efficiency rating of 77%, you can rest assured the unit releases minimal energy as heat, saving you the hassle of adding a heat sink to your board.

Features & Benefits

• Soft-start function for safe use with sensitive devices

• Rise-time of 900μs ensures rapid power switching

• Typical power dissipation of 0.75W means it's energy efficient

Applications

• Control panels

• Aerospace engineering

• Robotics systems

• Server rooms

What protective features does this converter have?

This converter features short-circuit protection with automatic recovery so it'll rapidly pick up in the event of an electric hazard. For added durability, the integrated overcurrent protection helps shield it from power surges.

Can I use this converter in vibrating machinery?

Yes, you can use this converter in vibrating conditions thanks to its built-in resistance to mechanical shock and random vibration.
