TRACOPOWER TEN 40WIE DC/DC Converter, 12V dc/ 3333 mA, 75V dc Input, 18V Input 40 W, Through Hole, 85 °C Max Temp -40 °C
- RS Stock No.:
- 194-4672
- Mfr. Part No.:
- TEN 40-4812WIE
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 tube of 10 units)*
£569.52
(exc. VAT)
£683.42
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 1 unit(s) shipping from 13 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £569.52 | £56.952 |
| 5 - 9 | £552.44 | £55.244 |
| 10 - 24 | £535.36 | £53.536 |
| 25 - 49 | £512.57 | £51.257 |
| 50 + | £489.78 | £48.978 |
*price indicative
- RS Stock No.:
- 194-4672
- Mfr. Part No.:
- TEN 40-4812WIE
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 75V dc | |
| Output Current 1 | 3333mA | |
| Mount Type | Through Hole | |
| Input Ratio | 4:1 | |
| MTBF | 1245000h | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±10 % | |
| Isolation Voltage | 1.6kV dc | |
| Number of Pins | 6 | |
| Package Type | DIP | |
| Maximum Output Power | 40W | |
| Depth | 10.2mm | |
| Width | 25.4mm | |
| Standards/Approvals | No | |
| Length | 50.8mm | |
| Series | TEN 40WIE | |
| Efficiency | 92% | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Minimum Input Voltage 18V | ||
Maximum Input Voltage 75V dc | ||
Output Current 1 3333mA | ||
Mount Type Through Hole | ||
Input Ratio 4:1 | ||
MTBF 1245000h | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±10 % | ||
Isolation Voltage 1.6kV dc | ||
Number of Pins 6 | ||
Package Type DIP | ||
Maximum Output Power 40W | ||
Depth 10.2mm | ||
Width 25.4mm | ||
Standards/Approvals No | ||
Length 50.8mm | ||
Series TEN 40WIE | ||
Efficiency 92% | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- TW
Traco Power DC-DC Converter, 92% Efficiency, 40W Power Rating - TEN 40WIE Series - TEN 40-4812WIE
Turn your voltage down a notch with this DC-DC converter from Traco Power. Thanks to its 4:1 ratio, it has a wide input between 18 and 75V DC, so you'll have no trouble matching it to your supply voltage. The converter safely lowers this to 12V DC, using functional isolation to keep the input and output electrically separated. Load regulation ensures a ±1% accuracy, enabling the unit to feed sensitive circuits. With a maximum efficiency of 92%, it won't waste power or run too hot.
Features & Benefits
• Remote on and off controls help you save power
• Trim function gives you an output voltage adjustment of ±10%
• Through-hole mounting for a secure connection to PCBs
• Wide operating temperature range between -40°C and +85°C, to handle harsh conditions
Applications
• Industrial machines
• Process control
• Safety systems
• IT equipment
• Production lines
Is this DC-DC converter reliable?
Yes. Protections against short circuits and overvoltage and a metal case that provides shielding on all sides make this DC-DC converter a reliable workmate.
