TRACOPOWER TBA 1E DC/DC Converter, 12V dc/ 41 mA, 26.4V dc Input, 21.6V Input 1 W, PCB, 85 °C Max Temp -40 °C Min Temp
- RS Stock No.:
- 187-4367
- Distrelec Article No.:
- 301-47-392
- Mfr. Part No.:
- TBA 1-2422E
- Brand:
- TRACOPOWER
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£3.31
(exc. VAT)
£3.97
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 19 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
- Plus 191 unit(s) shipping from 05 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £3.31 |
| 5 - 9 | £3.21 |
| 10 - 24 | £3.11 |
| 25 - 49 | £2.99 |
| 50 + | £2.85 |
*price indicative
- RS Stock No.:
- 187-4367
- Distrelec Article No.:
- 301-47-392
- Mfr. Part No.:
- TBA 1-2422E
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 26.4V dc | |
| Minimum Input Voltage | 21.6V | |
| Output Current 1 | 41mA | |
| Output Current 2 | 41mA | |
| Mount Type | PCB | |
| Output Voltage 2 | -12V dc | |
| MTBF | 2000000h | |
| Number of Outputs | 2 | |
| Isolation Voltage | 1.5kV dc | |
| Package Type | SIP-7 | |
| Maximum Output Power | 1W | |
| Standards/Approvals | No | |
| Depth | 9.55mm | |
| Width | 6mm | |
| Series | TBA 1E | |
| Length | 19.5mm | |
| Efficiency | 82% | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 26.4V dc | ||
Minimum Input Voltage 21.6V | ||
Output Current 1 41mA | ||
Output Current 2 41mA | ||
Mount Type PCB | ||
Output Voltage 2 -12V dc | ||
MTBF 2000000h | ||
Number of Outputs 2 | ||
Isolation Voltage 1.5kV dc | ||
Package Type SIP-7 | ||
Maximum Output Power 1W | ||
Standards/Approvals No | ||
Depth 9.55mm | ||
Width 6mm | ||
Series TBA 1E | ||
Length 19.5mm | ||
Efficiency 82% | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- CN
Traco Power DC-DC Converter, 2 Outputs, SIP Format - TBA 1E Series - TBA 1-2422E
Need a device that lowers voltages and gives you a dual output? This multitasking DC-DC converter from Traco Power fits the bill. It takes an input between 21.6 and 26.4V DC and delivers two outputs of ±12V DC, so you can power two circuits or a component that needs a positive and negative voltage. This makes it handy for switches, diodes and integrated circuits. As the unit saves space compared to using two single-output DC-DC converters and tips the scales at just 2.3g, it's a good solution for use with portable equipment. The SIP-7 format is simple to mount on standard PCBs, ensuring your electronics assembly is straightforward.
Features & Benefits
• Compact dimensions of 19.5 (L) x 6 (W) x 10 mm (D) take up minimal board space
• Integrated short-circuit protection to handle electrical faults
• 1W rating and an 82% efficiency keep energy consumption low
• 1,060V AC isolation keeps the input and outputs safely separated
Applications
• Electronics manufacturing
• Industrial controls
• Telecommunications industry
• IT networks
Does this DC-DC converter handle extreme temperatures?
It works in environments between -40°C and +85°C without derating. So there's no loss of performance in extreme temperatures.
