TRACOPOWER THL 15WI DC-DC Converter, 12V dc/ 1.25A Output, 9 → 36 V dc Input, 15W, Through Hole, +70°C Max Temp
- RS Stock No.:
- 186-0234
- Distrelec Article No.:
- 301-40-644
- Mfr. Part No.:
- THL 15-2412WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£25.53
(exc. VAT)
£30.64
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 7 unit(s) ready to ship
- Plus 4 unit(s) ready to ship from another location
- Plus 13 unit(s) shipping from 09 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £25.53 |
| 5 - 9 | £24.76 |
| 10 - 24 | £24.00 |
| 25 - 49 | £22.98 |
| 50 + | £21.95 |
*price indicative
- RS Stock No.:
- 186-0234
- Distrelec Article No.:
- 301-40-644
- Mfr. Part No.:
- THL 15-2412WI
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 12V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Power Rating | 15W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 1.25A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±10% | |
| Package | 1 x 1 in | |
| Isolation Voltage | 1kV dc | |
| Width | 25.4mm | |
| Depth | 10.16mm | |
| Length | 25.4mm | |
| Railway Approved | No | |
| Series | THL 15WI | |
| Load Regulation | 0.002 | |
| Efficiency | 88% | |
| Medical Approved | No | |
| Maximum Temperature | +70°C | |
| Minimum Temperature | -40°C | |
| Standards Met | IEC/EN 62368-1 | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 12V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 15W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 1.25A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±10% | ||
Package 1 x 1 in | ||
Isolation Voltage 1kV dc | ||
Width 25.4mm | ||
Depth 10.16mm | ||
Length 25.4mm | ||
Railway Approved No | ||
Series THL 15WI | ||
Load Regulation 0.002 | ||
Efficiency 88% | ||
Medical Approved No | ||
Maximum Temperature +70°C | ||
Minimum Temperature -40°C | ||
Standards Met IEC/EN 62368-1 | ||
