TRACOPOWER THL 15WI DC-DC Converter, 24V dc/ 625mA Output, 18 → 75 V dc Input, 15W, Through Hole, +70°C Max Temp
- RS Stock No.:
- 186-0218
- Distrelec Article No.:
- 301-40-652
- Mfr. Part No.:
- THL 15-4815WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£25.53
(exc. VAT)
£30.64
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 64 unit(s) ready to ship
- Plus 10 unit(s) shipping from 06 November 2025
- Plus 999,999,925 unit(s) shipping from 29 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £25.53 |
| 5 - 9 | £24.76 |
| 10 - 24 | £24.00 |
| 25 - 49 | £22.98 |
| 50 + | £21.95 |
*price indicative
- RS Stock No.:
- 186-0218
- Distrelec Article No.:
- 301-40-652
- Mfr. Part No.:
- THL 15-4815WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 24V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Power Rating | 15W | |
| Input Voltage Nominal | 48 V dc | |
| Output Current | 625mA | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±10% | |
| Package | 1 x 1 in | |
| Isolation Voltage | 1kV dc | |
| Width | 25.4mm | |
| Length | 25.4mm | |
| Depth | 10.16mm | |
| Series | THL 15WI | |
| Load Regulation | 0.002 | |
| Maximum Temperature | +70°C | |
| Efficiency | 91% | |
| Minimum Temperature | -40°C | |
| Standards Met | CB, EN 55024, EN 55032, EN 61000-4, IEC/EN 62368-1 | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 24V dc | ||
Input Voltage Range 18 → 75 V dc | ||
Power Rating 15W | ||
Input Voltage Nominal 48 V dc | ||
Output Current 625mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±10% | ||
Package 1 x 1 in | ||
Isolation Voltage 1kV dc | ||
Width 25.4mm | ||
Length 25.4mm | ||
Depth 10.16mm | ||
Series THL 15WI | ||
Load Regulation 0.002 | ||
Maximum Temperature +70°C | ||
Efficiency 91% | ||
Minimum Temperature -40°C | ||
Standards Met CB, EN 55024, EN 55032, EN 61000-4, IEC/EN 62368-1 | ||
- COO (Country of Origin):
- TW
TRACOPOWER THL 15WI Series DC-DC Converter, 18 to 75V DC Input Voltage Range, 15W Power Rating - THL 15-4815WI
This DC-DC converter is part of the THL 15WI series, offering a robust solution for a range of applications. It features a compact metal housing with dimensions of 25.4mm x 25.4mm x 10.16mm, an output voltage of 24V DC, and operates within a broad input voltage range of 18 to 75V DC. Designed for high efficiency, this converter ensures stable functionality in various environments.
Features & Benefits
• Efficiency of 91% minimises energy loss
• Isolated output promotes safety in sensitive applications
• Compact design optimises space on PCB
• Complies with IEC/EN 62368-1 standards for safety
• Isolated output promotes safety in sensitive applications
• Compact design optimises space on PCB
• Complies with IEC/EN 62368-1 standards for safety
Applications
• Suitable for mobile equipment
• Used in instrumentation systems
• Ideal for distributed power architectures
• Used in instrumentation systems
• Ideal for distributed power architectures
Can it operate in extreme temperatures?
Yes, it operates effectively from -40°C to +70°C.
Will it fit into a standard PCB design?
Its footprint of 1 x 1 allows for seamless integration.
Is it safe for sensitive electronics?
The isolated output ensures safe operation in such scenarios.
