Cosel MGXS6 DC/DC Converter, 15V dc/ 400 mA, 24V dc Input, 24V dc Input 6 W, Through Hole, 85 °C Max Temp -40 °C Min
- RS Stock No.:
- 183-0600
- Mfr. Part No.:
- MGXS62415
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£283.65
(exc. VAT)
£340.38
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 09 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £283.65 | £28.365 |
| 5 - 9 | £275.13 | £27.513 |
| 10 - 24 | £269.47 | £26.947 |
| 25 - 49 | £263.80 | £26.38 |
| 50 + | £258.13 | £25.813 |
*price indicative
- RS Stock No.:
- 183-0600
- Mfr. Part No.:
- MGXS62415
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage 1 | 15V dc | |
| Product Type | DC/DC Converter | |
| Minimum Input Voltage | 24V dc | |
| Maximum Input Voltage | 24V dc | |
| Output Current 1 | 400mA | |
| Mount Type | Through Hole | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 10 % | |
| Ripple and Noise | 400mV | |
| Number of Pins | 7 | |
| Isolation Voltage | 1kV dc | |
| Package Type | PCB Module | |
| Maximum Output Power | 6W | |
| Depth | 12mm | |
| Length | 22mm | |
| Standards/Approvals | Crlus, C-UL, EN60950-1, UL60950-1, CE | |
| Weight | 7g | |
| Width | 9.5mm | |
| Series | MGXS6 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 87% | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 1 15V dc | ||
Product Type DC/DC Converter | ||
Minimum Input Voltage 24V dc | ||
Maximum Input Voltage 24V dc | ||
Output Current 1 400mA | ||
Mount Type Through Hole | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 10 % | ||
Ripple and Noise 400mV | ||
Number of Pins 7 | ||
Isolation Voltage 1kV dc | ||
Package Type PCB Module | ||
Maximum Output Power 6W | ||
Depth 12mm | ||
Length 22mm | ||
Standards/Approvals Crlus, C-UL, EN60950-1, UL60950-1, CE | ||
Weight 7g | ||
Width 9.5mm | ||
Series MGXS6 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Efficiency 87% | ||
- COO (Country of Origin):
- JP
The Cosel DC-DC converter is designed for optimal efficiency in various electronic applications, featuring a wide input range of DC 36 to 76V for robust power management and reliable performance in stringent operational environments.
High efficiency of up to 89% ensures minimal power loss and reduced operational costs
Isolation input-output of DC 1,500V provides enhanced safety and reliability in electrical designs
Wide operating temperature range of -40 to +85°C allows for deployment in extreme environments
Dual output configuration supports versatile functionality, accommodating varied power requirements
