TRACOPOWER TEL 10WI DC-DC Converter, ±12V dc/ ±416mA Output, 9 → 36 V dc Input, 10W, Through Hole, +88°C Max

View all DC-DC Converters

Subtotal (1 unit)*

£24.90

(exc. VAT)

£29.88

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 6 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£24.90

*price indicative

RS Stock No.:
176-4650
Mfr. Part No.:
TEL 10-2422WI
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage

±12V dc

Input Voltage Range

9 → 36 V dc

Power Rating

10W

Input Voltage Nominal

24 V dc

Output Current

±416mA

Mounting Type

Through Hole

Isolated

Yes

Number of Outputs

2

Package

DIP-16

Isolation Voltage

1kV dc

Width

13.7mm

Depth

8mm

Length

23.8mm

Series

TEL 10WI

Load Regulation

0.01

Standards Met

EN 55032, IEC/EN/UL 60950-1, IEC/EN/UL 62368-1

Efficiency

87%

Minimum Temperature

-40°C

Maximum Temperature

+88°C

COO (Country of Origin):
TW

TRACOPOWER TEL 10WI Series DC-DC Converter, ±12V DC Output Voltage, 10W Power Rating - TEL 10-2422WI


This isolated DC-DC converter is designed for efficient power supply across various applications. It provides an output voltage of ±12V DC, with an input voltage range of 9 to 36V DC. Housed in a compact DIP-16 package, this 10W DC-DC converter ensures robust performance in challenging environments.

Features & Benefits


• Compact DIP-16metal casing optimises space usage
• Ultra wide input voltage range supports diverse applications
• High efficiency helps reduce thermal loss during operation
• Operating temperature range ensures reliability from -40°C to +88°C
• Built-in filters complies with various emissions standards
• Protection features ensures safe operation under short-circuit or overload conditions

Applications


• Used in automation systems for reliable power conversion
• Suitable for instrumentation in challenging environments
• Ideal for industrial electronics requiring compact power solutions
• Utilised in IT equipment for stable voltage supply
• Fit for use in electrical systems with space constraints

What is the efficiency level of this converter?


The high efficiency of this unit can reach up to 87%, ensuring lower thermal loss and higher reliability under load conditions. This makes it suitable for applications where energy conservation is key.

How does the design contribute to its performance?


The converter’s six-sided shielding and insulated base plate provide effective protection against external interference and enhance its thermal management capabilities, contributing to stable and reliable operation in critical environments.

What safety standards does this product meet?


This device meets various safety standards including EN 55032And IEC 62368-1, ensuring compliance in IT and multimedia applications, thereby facilitating safe use in commercial and industrial sectors.
