TRACOPOWER TEL 10WI DC/DC Converter, 15V dc/ 333 mA, 36V dc Input, 9V Input 10 W, PCB, 88 °C Max Temp -40 °C Min Temp

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£27.12

(exc. VAT)

£32.54

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 30 unit(s) ready to ship
  • Plus 10 unit(s) shipping from 05 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£27.12
5 - 9£26.31
10 - 24£25.49
25 - 49£24.40
50 +£23.32

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
176-4648
Distrelec Article No.:
301-40-634
Mfr. Part No.:
TEL 10-2423WI
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Product Type

DC/DC Converter

Output Voltage 1

15V dc

Minimum Input Voltage

9V

Maximum Input Voltage

36V dc

Output Current 1

333mA

Output Current 2

333mA

Output Voltage 2

-15V dc

Mount Type

PCB

Input Ratio

4:1

MTBF

2540000h

Number of Outputs

2

Isolation Voltage

1kV dc

Maximum Output Power

10W

Package Type

DIP-16

Depth

8mm

Series

TEL 10WI

Standards/Approvals

No

Width

13.7mm

Length

23.8mm

Better World Claim

Concentrated or Compact Solution

Better World Product

Yes

Efficiency

87%

Maximum Operating Temperature

88°C

Minimum Operating Temperature

-40°C

COO (Country of Origin):
TW

TRACOPOWER TEL 10WI Series DC-DC Converter, ±15V DC Output Voltage, 10W Power Rating - TEL 10-2423WI


This DC-DC converter is a compact power solution designed for efficient voltage conversion. With a power output of 10W and an isolated dual-output capability providing ±15V DC, this converter is suitable for applications where space and performance are critical. The unit measures 23.8mm in length, 13.7mm in width, and has a depth of 8mm, housed in a DIP-16metal casing.

Features & Benefits


• Ultra-wide 24V DC input range ensures versatile compatibility

• High efficiency of 87% minimises thermal losses

• Built-in protection circuitry guards against short circuits and overloads

• Compliance with EN 55032 ensures reduced electromagnetic interference

• Through hole mounting type offers easy integration into various circuits

• Operates effectively across a wide temperature range of -40°C to +88°C supports extreme conditions

Applications


• Ideal for instrumentation and automation systems requiring compact power

• Suitable for electronics in both industrial and IT environments

• Used in projects needing reliable dual output voltage solutions

• Can be integrated into space-constrained electrical designs

What is the maximum output current available from this converter?


It provides an output current of ±333mA at ±15V DC, ensuring sufficient power for many applications.

How does the efficiency of the converter impact its operation?


With an efficiency of 87%, it significantly reduces heat generation, allowing for reliable performance even under high-load conditions.

What kind of input voltage variations can this model tolerate?


It has an input voltage range of 9 to 36V DC, providing flexibility in various operational settings.

What environmental conditions can this unit operate under?


It functions effectively in temperatures ranging from -40°C to +88°C, making it suitable for a wide array of environments.
