TRACOPOWER TRS 2 DC-DC Converter, 3.3V dc/ 500mA Output, 18 → 36 V dc Input, 1.65W, Surface Mount, +90°C Max
- RS Stock No.:
- 176-4569
- Mfr. Part No.:
- TRS 2-2410
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£13.57
(exc. VAT)
£16.28
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 95 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £13.57 |
5 - 9 | £13.16 |
10 - 24 | £12.75 |
25 - 49 | £12.22 |
50 + | £11.66 |
*price indicative
- RS Stock No.:
- 176-4569
- Mfr. Part No.:
- TRS 2-2410
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 3.3V dc | |
Input Voltage Range | 18 → 36 V dc | |
Power Rating | 1.65W | |
Input Voltage Nominal | 24 V dc | |
Output Current | 500mA | |
Mounting Type | Surface Mount | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | SMD-7 | |
Isolation Voltage | 1.6kV dc | |
Width | 11.3mm | |
Length | 11.9mm | |
Depth | 7.6mm | |
Series | TRS 2 | |
Load Regulation | 0.01 | |
Standards Met | EN 55032 Class A or B, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, UL 62368-1 | |
Efficiency | 77% | |
Maximum Temperature | +90°C | |
Minimum Temperature | -40°C | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 3.3V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 1.65W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 500mA | ||
Mounting Type Surface Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SMD-7 | ||
Isolation Voltage 1.6kV dc | ||
Width 11.3mm | ||
Length 11.9mm | ||
Depth 7.6mm | ||
Series TRS 2 | ||
Load Regulation 0.01 | ||
Standards Met EN 55032 Class A or B, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, UL 62368-1 | ||
Efficiency 77% | ||
Maximum Temperature +90°C | ||
Minimum Temperature -40°C | ||
- COO (Country of Origin):
- TW
Traco Power DC-DC Converter, 1.65W Power Rating, 77% Efficiency - TRS 2 Series - TRS 2-2410
For a balanced voltage supply in your compact application, pick this DC-DC converter from Traco Power. It has a footprint of just 11.9 (L) x 11.3 (W) x 7.6mm (D), making it a sure fit on densely packed PCBs or panels. The unit changes inputs between 18 and 36V DC into a stable 3.3V DC supply for the smooth operation of your low-voltage system. Load regulation of 0.01% keeps the output steady, even when incoming feeds have their ups and downs.
Features & Benefits
• Reliable performance in a wide temperature range of -40°C and +90°C
• Isolation between inputs and outputs helps prevent damage and electric shocks
• EMI-resistant housing ensures electrostatic discharges and electromagnetic fields don't disrupt performance
• Isolation between inputs and outputs helps prevent damage and electric shocks
• EMI-resistant housing ensures electrostatic discharges and electromagnetic fields don't disrupt performance
Applications
• IT networks
• Consumer electronics
• Testing and measurement devices
• Industrial control equipment
• Consumer electronics
• Testing and measurement devices
• Industrial control equipment
What's the power rating of this DC-DC converter?
It has a power rating of just 1.65W, so it's an energy-efficient unit that consumes little energy.
How do I mount this DC-DC converter?
Mounting only takes a second – just slot the pins into your PCB or panel and solder the unit securely in place.
