Artesyn ERM DC-DC Converter, 24V dc/ 830mA Output, 40 → 160 V dc Input, 20W, Through Hole, +85°C Max Temp -40°C
- RS Stock No.:
- 174-3454
- Mfr. Part No.:
- ERM01H110B
- Brand:
- Artesyn
Save 11% when you buy 50 units
Subtotal (1 tube of 10 units)*
£571.84
(exc. VAT)
£686.21
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 07 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £571.84 | £57.184 |
| 5 - 9 | £554.68 | £55.468 |
| 10 - 24 | £537.53 | £53.753 |
| 25 - 49 | £520.37 | £52.037 |
| 50 + | £503.22 | £50.322 |
*price indicative
- RS Stock No.:
- 174-3454
- Mfr. Part No.:
- ERM01H110B
- Brand:
- Artesyn
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Artesyn | |
| Output Voltage | 24V dc | |
| Input Voltage Range | 40 → 160 V dc | |
| Power Rating | 20W | |
| Input Voltage Nominal | 110 V dc | |
| Output Current | 830mA | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | DIP | |
| Isolation Voltage | 3kV dc | |
| Depth | 11mm | |
| Width | 25.4mm | |
| Length | 50.8mm | |
| Railway Approved | Yes | |
| Series | ERM | |
| Load Regulation | ±0.5% | |
| Efficiency | 86% | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
| Standards Met | EN45545-2, EN50121-3-2, IEC/EN 50155 (IEC60571), IEC/EN 62368-1 (60950-1), UL/cUL 62368-1 (60950-1) | |
Select all | ||
|---|---|---|
Brand Artesyn | ||
Output Voltage 24V dc | ||
Input Voltage Range 40 → 160 V dc | ||
Power Rating 20W | ||
Input Voltage Nominal 110 V dc | ||
Output Current 830mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package DIP | ||
Isolation Voltage 3kV dc | ||
Depth 11mm | ||
Width 25.4mm | ||
Length 50.8mm | ||
Railway Approved Yes | ||
Series ERM | ||
Load Regulation ±0.5% | ||
Efficiency 86% | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
Standards Met EN45545-2, EN50121-3-2, IEC/EN 50155 (IEC60571), IEC/EN 62368-1 (60950-1), UL/cUL 62368-1 (60950-1) | ||
