Artesyn AYA DC-DC Converter, 12V dc/ 160mA Output, 18 → 36 V dc Input, 2W, Through Hole, +85°C Max Temp -40°C
- RS Stock No.:
- 174-3365
- Mfr. Part No.:
- AYA00B24-L
- Brand:
- Artesyn
Available to back order for despatch 11/02/2025
Added
Price 1 Tube of 10
£174.47
(exc. VAT)
£209.36
(inc. VAT)
Tube(s) | Per Tube | Per unit* |
1 - 4 | £174.47 | £17.447 |
5 - 9 | £169.24 | £16.924 |
10 - 24 | £164.01 | £16.401 |
25 - 49 | £158.77 | £15.877 |
50 + | £153.54 | £15.354 |
*price indicative |
- RS Stock No.:
- 174-3365
- Mfr. Part No.:
- AYA00B24-L
- Brand:
- Artesyn
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Artesyn Embedded Technologies has series of AYA 2W isolated DC-DC converter through hole, input voltage of 18V to 36V dc and output voltage of 12V dc.
Efficiency up to 87%
I/O-isolation 1500 Vdc
Wide 2: 1 input range
Operating temperature range: -40 °C to +85 °C
I/O-isolation 1500 Vdc
Wide 2: 1 input range
Operating temperature range: -40 °C to +85 °C
Specifications
Attribute | Value |
---|---|
Output Voltage | 12V dc |
Input Voltage Range | 18 → 36 V dc |
Power Rating | 2W |
Input Voltage Nominal | 24 V dc |
Output Current | 160mA |
Mounting Type | Through Hole |
Isolated | Yes |
Number of Outputs | 1 |
Package | DIP |
Isolation Voltage | 1.5kV dc |
Depth | 8mm |
Length | 14mm |
Width | 14mm |
Series | AYA |
Load Regulation | 0.01 |
Maximum Temperature | +85°C |
Efficiency | 87% |
Minimum Temperature | -40°C |
Standards Met | CE Certified, cUL/UL 60950-1, UL/cUL/IEC/EN 60950-1 |
