Artesyn AEE15W-M DC-DC Converter, ±15V dc/ 500mA Output, 9 → 18 V dc Input, 15W, Through Hole, +80°C Max Temp
- RS Stock No.:
- 174-3328
- Mfr. Part No.:
- AEE01CC12-M
- Brand:
- Artesyn
Bulk discount available
Subtotal (1 tube of 10 units)*
£538.83
(exc. VAT)
£646.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 29 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
---|---|---|
1 - 4 | £538.83 | £53.883 |
5 - 9 | £522.66 | £52.266 |
10 - 24 | £506.50 | £50.65 |
25 - 49 | £490.33 | £49.033 |
50 + | £474.17 | £47.417 |
*price indicative
- RS Stock No.:
- 174-3328
- Mfr. Part No.:
- AEE01CC12-M
- Brand:
- Artesyn
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Artesyn | |
Output Voltage | ±15V dc | |
Input Voltage Range | 9 → 18 V dc | |
Power Rating | 15W | |
Input Voltage Nominal | 12 V dc | |
Output Current | 500mA | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 2 | |
Package | 2 in x 1 in Case | |
Isolation Voltage | 4.2kV dc | |
Depth | 12mm | |
Width | 25.4mm | |
Length | 50.8mm | |
Series | AEE15W-M | |
Load Regulation | 0.01 | |
Standards Met | ANSI/AAMI ES60601-1, Class A, EMI EN55011, EMS EN60601-1-2, EN 55022, EN/IEC 60601-1, FCC, Level A | |
Maximum Temperature | +80°C | |
Medical Approved | Yes | |
Minimum Temperature | -40°C | |
Efficiency | 89% | |
Select all | ||
---|---|---|
Brand Artesyn | ||
Output Voltage ±15V dc | ||
Input Voltage Range 9 → 18 V dc | ||
Power Rating 15W | ||
Input Voltage Nominal 12 V dc | ||
Output Current 500mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Package 2 in x 1 in Case | ||
Isolation Voltage 4.2kV dc | ||
Depth 12mm | ||
Width 25.4mm | ||
Length 50.8mm | ||
Series AEE15W-M | ||
Load Regulation 0.01 | ||
Standards Met ANSI/AAMI ES60601-1, Class A, EMI EN55011, EMS EN60601-1-2, EN 55022, EN/IEC 60601-1, FCC, Level A | ||
Maximum Temperature +80°C | ||
Medical Approved Yes | ||
Minimum Temperature -40°C | ||
Efficiency 89% | ||
The ERM20 series of high performance 20 watt isolated DC-DC converter modules are designed specifically for railway applications. There is a choice of four single output models, offering single output voltages of 5 V, 12 V, 15 V or 24 V, and dual +/-12 and +/-15 versions.Fully encapsulated in a metal case the converters have an industry-standard 2 x 1 inch (50.9 x 25.4mm) footprint and a height of just 0.43 inch (11 mm). Reinforced insulation rated at 3000 Vac rms and high EMI immunity qualifies these converters for many demanding applications in railway and other transportation systems.
Advanced circuit topology provides up to 88% efficiency and allows the converters to accommodate ambient operating temperatures as high as 85˚C with suitable derating.
Advanced circuit topology provides up to 88% efficiency and allows the converters to accommodate ambient operating temperatures as high as 85˚C with suitable derating.
SPECIAL FEATURES
Encapsulated
Wide 4:1 input range
1 x 2 DIP package
3000 Vac rms I/O isolation
Single and dual output
OCP, OVP, OTP Protection
Remote On/Off
High efficiency - 88%
Encapsulated
Wide 4:1 input range
1 x 2 DIP package
3000 Vac rms I/O isolation
Single and dual output
OCP, OVP, OTP Protection
Remote On/Off
High efficiency - 88%
