TRACOPOWER TEC 2WI DC-DC Converter, 5V dc/ 400mA Output, 18 → 75 V dc Input, 2W, Through Hole, +93°C Max Temp
- RS Stock No.:
- 174-2302
- Mfr. Part No.:
- TEC 2-4811WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£10.01
(exc. VAT)
£12.01
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 29 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £10.01 |
5 - 9 | £9.70 |
10 - 24 | £9.40 |
25 - 49 | £9.01 |
50 + | £8.60 |
*price indicative
- RS Stock No.:
- 174-2302
- Mfr. Part No.:
- TEC 2-4811WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 5V dc | |
Input Voltage Range | 18 → 75 V dc | |
Power Rating | 2W | |
Input Voltage Nominal | 48 V dc | |
Output Current | 400mA | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | SIP-8 | |
Isolation Voltage | 1.6kV dc | |
Width | 9.1mm | |
Depth | 11.2mm | |
Length | 21.8mm | |
Series | TEC 2WI | |
Load Regulation | 0.01 | |
Efficiency | 80% | |
Minimum Temperature | -40°C | |
Maximum Temperature | +93°C | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 5V dc | ||
Input Voltage Range 18 → 75 V dc | ||
Power Rating 2W | ||
Input Voltage Nominal 48 V dc | ||
Output Current 400mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package SIP-8 | ||
Isolation Voltage 1.6kV dc | ||
Width 9.1mm | ||
Depth 11.2mm | ||
Length 21.8mm | ||
Series TEC 2WI | ||
Load Regulation 0.01 | ||
Efficiency 80% | ||
Minimum Temperature -40°C | ||
Maximum Temperature +93°C | ||
- COO (Country of Origin):
- TW
TRACOPOWER TEC 2WI Series DC-DC Converter, 5V DC Output Voltage, 400mA Output Current - TEC 2-4811WI
This isolated DC-DC converter is designed for versatile applications requiring reliable voltage conversion. The unit operates efficiently within an input voltage range of 18-75V DC and provides a regulated output of 5V DC at 400mA. Encased in a compact SIP-8 package, it measures 21.8mm in length, 9.m in width, and 11.2mm in depth. Its robust design ensures performance under varying environmental conditions.
Features & Benefits
• Ultra-wide input voltage range accommodates diversity
• Continuous short circuit protection enhances reliability
• Fully regulated outputs ensures stable performance under load
• Remote On/Off control for convenient operation
• High efficiency of 79% reduces energy wastage
• Operating temperature range of -40°C to +93°C ensures versatile use
• Continuous short circuit protection enhances reliability
• Fully regulated outputs ensures stable performance under load
• Remote On/Off control for convenient operation
• High efficiency of 79% reduces energy wastage
• Operating temperature range of -40°C to +93°C ensures versatile use
Applications
• Utilised in automation and control systems for reliable power management
• Suitable for telecommunications and networking equipment
• Employed in industrial automation solutions to convert high voltage
• Ideal for battery-powered devices requiring efficient voltage regulation
• Suitable for telecommunications and networking equipment
• Employed in industrial automation solutions to convert high voltage
• Ideal for battery-powered devices requiring efficient voltage regulation
What type of isolation does this unit provide?
It offers an isolation voltage of 1.6kV DC between the input and output, ensuring safe operation in sensitive applications.
How does this converter manage thermal issues in high-temperature situations?
With an operational temperature range from -40°C to +93°C, it is designed to function efficiently, even under demanding thermal conditions, while maintaining a power derating of 4.8% per Kelvin above 84°C.
Can this product handle sudden increases in voltage?
Yes, it features a surge voltage capability, allowing it to withstand up to 100V DC for 1 second, providing added resilience against voltage spikes.
