Artesyn Embedded Technologies AXA DC-DC Converter, 24V dc/ 410mA Output, 18 → 75 V dc Input, 10W, Through Hole,
- RS Stock No.:
- 173-9183
- Mfr. Part No.:
- AXA000H36-L
- Brand:
- Artesyn Embedded Technologies
Available to back order for despatch 06/08/2024
Added
Price 1 Tube of 10
£285.33
(exc. VAT)
£342.40
(inc. VAT)
| Tube(s) | Per Tube | Per unit* |
| 1 - 4 | £285.33 | £28.533 |
| 5 - 9 | £277.40 | £27.74 |
| 10 - 24 | £269.91 | £26.991 |
| 25 - 49 | £262.80 | £26.28 |
| 50 + | £256.06 | £25.606 |
| *price indicative | ||
- RS Stock No.:
- 173-9183
- Mfr. Part No.:
- AXA000H36-L
- Brand:
- Artesyn Embedded Technologies
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Artesyn AXA Series Isolated DC / DC Converter
Artesyn AXA series of isolated DC / DC converters offer an ultra compact DIP or SIP package, with a low profile of 8 mm. The series offers a highly efficient option of up to 87% with an ultra-wide 4:1 input range. The AXA series alows offers a remote on/off functionality, adding an extra layer of customisation for your application.
The AXA series is also qualified for lead-free reflow solder process according to IPC/JEDEC J-STD-020D.
The AXA series is also qualified for lead-free reflow solder process according to IPC/JEDEC J-STD-020D.
Features and Benefits
Single & dual output.
Ultra compact DIP & SIP options.
Metal cased with isolated baseplate.
Remote on/off functionality.
Input filter adheres to EN55022, class A & FCC level A.
Standards
UL/cUL 60950-1, IEC/EN 60950-1
Artesyn Isolated DC / DC Converter
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 24V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 10W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 410mA |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Isolation Voltage | 1.5kV dc |
| Width | 25.4mm |
| Depth | 10.16mm |
| Length | 25.4mm |
| Series | AXA |
| Load Regulation | -0.5 → +0.5% |
| Minimum Temperature | -40°C |
| Efficiency | 86% |
| Standards Met | CB Scheme, CSA Certificate, cUL/UL 60950-1, EN55022, FCC, IEC/EN 60950-1 |
| Maximum Temperature | +80°C |
