XP Power QSC150 DC-DC Converter, 48V dc/ 3.2A Output, 9 → 36 V dc Input, 150W, PCB Mount, +105°C Max Temp -40°C

RS Stock No.:: 172-3077
Distrelec Article No.:: 302-41-815
Mfr. Part No.:: QSC15024S48
Brand:: XP Power

XP Power QSC150 DC-DC Converter, 48V dc/ 3.2A Output, 9 → 36 V dc Input, 150W, PCB Mount, +105°C Max Temp -40°C

Bulk discount available

Price Each**

£143.58

(exc. VAT)

£172.30

(inc. VAT)

Available to back order for despatch 15/04/2025*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over £50.00

Units	Per unit
1 - 4	£143.58
5 - 9	£139.27
10 - 24	£134.98
25 - 49	£130.66
50 +	£126.35

**price indicative

RS Stock No.:: 172-3077
Distrelec Article No.:: 302-41-815
Mfr. Part No.:: QSC15024S48
Brand:: XP Power

Datasheets

Attribute	Value
Output Voltage	48V dc
Input Voltage Range	9 → 36 V dc
Power Rating	150W
Input Voltage Nominal	24 V dc
Output Current	3.2A
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	1
Package	Quarter Brick
Isolation Voltage	2.25kV dc
Length	57.9mm
Depth	12.7mm
Width	36.8mm
Series	QSC150
Load Regulation	±0.2%
Standards Met	EN 50121-3-2, EN 50155, EN 55024, EN 55032, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 62368-1, IEC/EN 60068-2-1, IEC/EN 60068-2-2, IEC/EN 60068-2-30, IEC/EN 61373, IEC60571, MIL-HDBK-217F, UL/cUL 62368-1
Maximum Temperature	+105°C
Minimum Temperature	-40°C

XP Power QSC150 DC-DC Converter, 48V dc/ 3.2A Output, 9 → 36 V dc Input, 150W, PCB Mount, +105°C Max Temp -40°C
