Artesyn Embedded Technologies ERM50 DC-DC Converter, 15V dc/ 3.33A Output, 66 → 160 V dc Input, 50W, Through
- RS Stock No.:
- 172-0309
- Mfr. Part No.:
- ERM03C110
- Brand:
- Artesyn Embedded Technologies
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 172-0309
- Mfr. Part No.:
- ERM03C110
- Brand:
- Artesyn Embedded Technologies
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Artesyn Embedded Technologies | |
| Output Voltage | 15V dc | |
| Input Voltage Range | 66 → 160 V dc | |
| Power Rating | 50W | |
| Input Voltage Nominal | 110 V dc | |
| Output Current | 3.33A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Isolation Voltage | 1.5kV dc | |
| Width | 36.8mm | |
| Depth | 12.7mm | |
| Length | 57.9mm | |
| Railway Approved | Yes | |
| Series | ERM50 | |
| Load Regulation | ±0.3% | |
| Efficiency | 92% | |
| Maximum Temperature | +85°C | |
| Standards Met | CE, cUL/UL 60950-1, EN 45545-2, EN 50121-3-2, EN 50155, EN 60950-1, EN 61373, IEC 60571, IEC/EN 5055, IEC/EN 60950-1 | |
| Minimum Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand Artesyn Embedded Technologies | ||
Output Voltage 15V dc | ||
Input Voltage Range 66 → 160 V dc | ||
Power Rating 50W | ||
Input Voltage Nominal 110 V dc | ||
Output Current 3.33A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Isolation Voltage 1.5kV dc | ||
Width 36.8mm | ||
Depth 12.7mm | ||
Length 57.9mm | ||
Railway Approved Yes | ||
Series ERM50 | ||
Load Regulation ±0.3% | ||
Efficiency 92% | ||
Maximum Temperature +85°C | ||
Standards Met CE, cUL/UL 60950-1, EN 45545-2, EN 50121-3-2, EN 50155, EN 60950-1, EN 61373, IEC 60571, IEC/EN 5055, IEC/EN 60950-1 | ||
Minimum Temperature -40°C | ||
