Artesyn Embedded Technologies ERM50 DC-DC Converter, 15V dc/ 3.33A Output, 43 → 101 V dc Input, 50W, Through
- RS Stock No.:
- 172-0277
- Mfr. Part No.:
- ERM03C72
- Brand:
- Artesyn Embedded Technologies
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 172-0277
- Mfr. Part No.:
- ERM03C72
- Brand:
- Artesyn Embedded Technologies
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Artesyn Embedded Technologies | |
Output Voltage | 15V dc | |
Input Voltage Range | 43 → 101 V dc | |
Power Rating | 50W | |
Input Voltage Nominal | 72 V dc | |
Output Current | 3.33A | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 1 | |
Isolation Voltage | 1.5kV dc | |
Width | 36.8mm | |
Length | 57.9mm | |
Depth | 12.7mm | |
Series | ERM50 | |
Railway Approved | Yes | |
Load Regulation | ±0.3% | |
Maximum Temperature | +85°C | |
Efficiency | 92% | |
Minimum Temperature | -40°C | |
Standards Met | CE, cUL/UL 60950-1, EN 45545-2, EN 50121-3-2, EN 50155, EN 60950-1, EN 61373, IEC 60571, IEC/EN 5055, IEC/EN 60950-1 | |
Select all | ||
---|---|---|
Brand Artesyn Embedded Technologies | ||
Output Voltage 15V dc | ||
Input Voltage Range 43 → 101 V dc | ||
Power Rating 50W | ||
Input Voltage Nominal 72 V dc | ||
Output Current 3.33A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Isolation Voltage 1.5kV dc | ||
Width 36.8mm | ||
Length 57.9mm | ||
Depth 12.7mm | ||
Series ERM50 | ||
Railway Approved Yes | ||
Load Regulation ±0.3% | ||
Maximum Temperature +85°C | ||
Efficiency 92% | ||
Minimum Temperature -40°C | ||
Standards Met CE, cUL/UL 60950-1, EN 45545-2, EN 50121-3-2, EN 50155, EN 60950-1, EN 61373, IEC 60571, IEC/EN 5055, IEC/EN 60950-1 | ||
- COO (Country of Origin):
- PH
The ERM50 series high performance 50 watt isolated DC-DC converter modules are designed specifically for railway applications. The high input versions feature a 66 to 160 Vdc input for equipment used on railway rolling stock. There is a choice of four single output models, offering voltages of 5 V, 12 V, 15 V or 24 V. Fully encapsulated in a metal case with an isolated baseplate, the converters have an industry-standard 2.28 x 1.45 inch (57.9 x 36.8mm) quarter-brick footprint and a height of just 0.5 inch (12.7 mm).
Small 57.9 x 36.8 x12.7 mm package
Input Range 43 - 101 Vdc
High Efficiency up to 92%
No Minimum Load Requirement
Operating Temp. Range -40 °C to +85 °C
Reinforced Insulation 3000 VACrms
Under-Voltage Shutdown
Remote On/Off
Metal Case with Isolated
Baseplate
Input Range 43 - 101 Vdc
High Efficiency up to 92%
No Minimum Load Requirement
Operating Temp. Range -40 °C to +85 °C
Reinforced Insulation 3000 VACrms
Under-Voltage Shutdown
Remote On/Off
Metal Case with Isolated
Baseplate
