Artesyn / Advanced Energy ATA DC-DC Converter, 5V dc/ 1.6A Output, 9 → 36 V dc Input, 8W, Through Hole, +80°C
- RS Stock No.:
- 172-0243
- Mfr. Part No.:
- ATA02A18-L
- Brand:
- Artesyn / Advanced Energy
Bulk discount available
Subtotal (1 unit)*
£28.02
(exc. VAT)
£33.62
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £28.02 |
| 5 - 9 | £26.89 |
| 10 - 24 | £26.05 |
| 25 - 49 | £24.66 |
| 50 + | £22.97 |
*price indicative
- RS Stock No.:
- 172-0243
- Mfr. Part No.:
- ATA02A18-L
- Brand:
- Artesyn / Advanced Energy
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Artesyn / Advanced Energy | |
| Output Voltage | 5V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Power Rating | 8W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 1.6A | |
| Mounting Type | Through Hole | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Package | DIP-6 | |
| Isolation Voltage | 1.5kV dc | |
| Width | 13.7mm | |
| Length | 23.8mm | |
| Depth | 8mm | |
| Series | ATA | |
| Load Regulation | 0.01 | |
| Maximum Temperature | +80°C | |
| Efficiency | 82% | |
| Minimum Temperature | -40°C | |
| Standards Met | CE, EN 55022, FCC, IEC/EN 60950-1, IEC/EN 62368-1, UL/cUL 60950-1, UL/cUL 62368-1, UL/cUL/IEC/EN 62368-1 | |
Select all | ||
|---|---|---|
Brand Artesyn / Advanced Energy | ||
Output Voltage 5V dc | ||
Input Voltage Range 9 → 36 V dc | ||
Power Rating 8W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 1.6A | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package DIP-6 | ||
Isolation Voltage 1.5kV dc | ||
Width 13.7mm | ||
Length 23.8mm | ||
Depth 8mm | ||
Series ATA | ||
Load Regulation 0.01 | ||
Maximum Temperature +80°C | ||
Efficiency 82% | ||
Minimum Temperature -40°C | ||
Standards Met CE, EN 55022, FCC, IEC/EN 60950-1, IEC/EN 62368-1, UL/cUL 60950-1, UL/cUL 62368-1, UL/cUL/IEC/EN 62368-1 | ||
