Artesyn Embedded Technologies ATA DC-DC Converter, 3.3V dc/ 2A Output, 18 → 75 V dc Input, 6.6W, Through Hole,
- RS Stock No.:
- 172-0206
- Mfr. Part No.:
- ATA02F36-L
- Brand:
- Artesyn Embedded Technologies
Available to back order for despatch 11/10/2024
Price 1 Tube of 10
£280.98
(exc. VAT)
£337.18
(inc. VAT)
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £280.98 | £28.098 |
| 5 - 9 | £269.74 | £26.974 |
| 10 - 24 | £261.31 | £26.131 |
| 25 - 49 | £247.26 | £24.726 |
| 50 + | £230.40 | £23.04 |
*price indicative
- RS Stock No.:
- 172-0206
- Mfr. Part No.:
- ATA02F36-L
- Brand:
- Artesyn Embedded Technologies
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Artesyn’s ATA series 6 watt isolated DC-DC converters are suitable for a diverse range of low power applications, including data communication, telecommunication and computer peripheral equipment, industrial automation and mobile battery-powered systems. The series comprises 14 variants, each of which is available in a mini dual-in-line package for through-hole mounting. All ATA series 6 watt converters feature ultra-wide 4:1 inputs: seven of the models have 9–36 V inputs and the other seven have 18–75 V inputs.
Ultra compact DIP package
23.8 x 13.7 x 8.0 mm
(0.94 x 0.54 x 0.31 inches)
Efficiency up to 80%
I/O-isolation 1500 VDC
Ultra-wide 4:1 input range
Operating temp. range -40, +80 (for DIP module)
Remote On/Off control
3 years product warranty
23.8 x 13.7 x 8.0 mm
(0.94 x 0.54 x 0.31 inches)
Efficiency up to 80%
I/O-isolation 1500 VDC
Ultra-wide 4:1 input range
Operating temp. range -40, +80 (for DIP module)
Remote On/Off control
3 years product warranty
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 3.3V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 6.6W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 2A |
| Mounting Type | Through Hole |
| Isolated | Yes |
| Number of Outputs | 1 |
| Package | DIP-6 |
| Isolation Voltage | 1.5kV dc |
| Length | 23.8mm |
| Width | 13.7mm |
| Depth | 8mm |
| Series | ATA |
| Load Regulation | 0.01 |
| Standards Met | CE, EN 55022, FCC, IEC/EN 60950-1, IEC/EN 62368-1, UL/cUL 60950-1, UL/cUL 62368-1, UL/cUL/IEC/EN 62368-1 |
| Maximum Temperature | +80°C |
| Efficiency | 78% |
| Minimum Temperature | -40°C |
