Artesyn / Advanced Energy ERM50 DC/DC Converter, 5V dc/ 10 A, 160V dc Input, 66V Input 50 W, Through Hole, 85 °C Max

View all DC-DC Converters
Bulk discount available

Subtotal (1 tube of 5 units)*

£636.22

(exc. VAT)

£763.46

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 29 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Tube(s)
Per Tube
Per unit*
1 - 4£636.22£127.244
5 - 9£610.77£122.154
10 - 24£591.68£118.336
25 - 49£559.87£111.974
50 +£521.70£104.34

*price indicative

RS Stock No.:
172-0176
Mfr. Part No.:
ERM10A110
Brand:
Artesyn / Advanced Energy
Find similar products by selecting one or more attributes.
Select all

Brand

Artesyn / Advanced Energy

Product Type

DC/DC Converter

Output Voltage 1

5V dc

Minimum Input Voltage

66V

Maximum Input Voltage

160V dc

Output Current 1

10A

Mount Type

Through Hole

Number of Outputs

1

MTBF

472000h

Isolation Voltage

1.5kV dc

Package Type

DIP

Maximum Output Power

50W

Series

ERM50

Width

36.8mm

Standards/Approvals

No

Depth

12.7mm

Length

57.9mm

Maximum Operating Temperature

85°C

Efficiency

90%

Minimum Operating Temperature

-40°C

COO (Country of Origin):
TW
The ERM50 series high performance 50 watt isolated DC-DC converter modules are designed specifically for railway applications. The high input versions feature a 66 to 160 Vdc input for equipment used on railway rolling stock. There is a choice of four single output models, offering voltages of 5 V, 12 V, 15 V or 24 V. Fully encapsulated in a metal case with an isolated baseplate, the converters have an industry-standard 2.28 x 1.45 inch (57.9 x 36.8mm) quarter-brick footprint and a height of just 0.5 inch (12.7 mm).

Small 57.9 x 36.8 x12.7 mm package

Input Range 66-160 Vdc

High Efficiency up to 92%

No Minimum Load Requirement

Operating Temp. Range -40 °C to +85 °C

Reinforced Insulation 3000 VACrms

Under-Voltage Shutdown

Remote On/Off

Metal Case with Isolated

Baseplate
