Cosel MGS DC/DC Converter, 3.3V dc/ 2.6 A, 24V dc Input, 18V Input 8.58 W, PCB, 85 °C Max Temp -40 °C Min Temp, 7-Pin
- RS Stock No.:
- 171-5073
- Mfr. Part No.:
- MGS10243R3
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£24.95
(exc. VAT)
£29.94
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 09 February 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £24.95 |
| 5 - 9 | £24.19 |
| 10 - 24 | £23.69 |
| 25 - 49 | £23.19 |
| 50 + | £22.69 |
*price indicative
- RS Stock No.:
- 171-5073
- Mfr. Part No.:
- MGS10243R3
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 3.3V dc | |
| Maximum Input Voltage | 24V dc | |
| Minimum Input Voltage | 18V | |
| Output Current 1 | 2.6A | |
| Output Current 2 | 2.6A | |
| Mount Type | PCB | |
| Number of Outputs | 1 | |
| Ripple and Noise | 300mV Pk-Pk | |
| Output Voltage Adjustment Range | 3.21 to 3.42 V | |
| Isolation Voltage | 1kV dc | |
| Number of Pins | 7 | |
| Maximum Output Power | 8.58W | |
| Package Type | SIP-8 | |
| Depth | 12mm | |
| Length | 22mm | |
| Series | MGS | |
| Width | 9.5mm | |
| Standards/Approvals | UKCA, CE, RoHS, C-UL, UL60950-1, UL62368-1, CSA, EN62368-1, EN 62368-1, cUL | |
| Weight | 7g | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 87% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 3.3V dc | ||
Maximum Input Voltage 24V dc | ||
Minimum Input Voltage 18V | ||
Output Current 1 2.6A | ||
Output Current 2 2.6A | ||
Mount Type PCB | ||
Number of Outputs 1 | ||
Ripple and Noise 300mV Pk-Pk | ||
Output Voltage Adjustment Range 3.21 to 3.42 V | ||
Isolation Voltage 1kV dc | ||
Number of Pins 7 | ||
Maximum Output Power 8.58W | ||
Package Type SIP-8 | ||
Depth 12mm | ||
Length 22mm | ||
Series MGS | ||
Width 9.5mm | ||
Standards/Approvals UKCA, CE, RoHS, C-UL, UL60950-1, UL62368-1, CSA, EN62368-1, EN 62368-1, cUL | ||
Weight 7g | ||
Maximum Operating Temperature 85°C | ||
Efficiency 87% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
Industry Standard
High efficiency by synchronized rectification circuit
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in remote ON/OFF
High reliability : not built-in aluminium and tantalum electrolytic capacitor
