Cosel MGW DC/DC Converter, 12V dc, -12 V dc/ 250 mA, 5V dc Input, 4.5V Input 6 W, PCB, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 171-4770
- Mfr. Part No.:
- MGW60512
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£177.17
(exc. VAT)
£212.60
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £177.17 | £17.717 |
| 5 - 9 | £171.85 | £17.185 |
| 10 - 24 | £168.31 | £16.831 |
| 25 - 49 | £164.77 | £16.477 |
| 50 + | £161.22 | £16.122 |
*price indicative
- RS Stock No.:
- 171-4770
- Mfr. Part No.:
- MGW60512
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 12, -12V dc | |
| Minimum Input Voltage | 4.5V | |
| Maximum Input Voltage | 5V dc | |
| Output Current 1 | 250mA | |
| Output Current 2 | 0.2A | |
| Mount Type | PCB | |
| Output Voltage 2 | 15V | |
| Number of Outputs | 2 | |
| Ripple and Noise | 200mV Pk-Pk | |
| Output Voltage Adjustment Range | 11.64 to 12.36 V | |
| Isolation Voltage | 1kV dc | |
| Number of Pins | 7 | |
| Package Type | SIP-8 | |
| Maximum Output Power | 6W | |
| Weight | 7g | |
| Standards/Approvals | EN62368-1, EN 62368-1, RoHS, CE, cUL, UL62368-1, UKCA, C-UL, CSA, UL60950-1 | |
| Width | 9.5mm | |
| Series | MGW | |
| Length | 22mm | |
| Depth | 12mm | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 87% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 12, -12V dc | ||
Minimum Input Voltage 4.5V | ||
Maximum Input Voltage 5V dc | ||
Output Current 1 250mA | ||
Output Current 2 0.2A | ||
Mount Type PCB | ||
Output Voltage 2 15V | ||
Number of Outputs 2 | ||
Ripple and Noise 200mV Pk-Pk | ||
Output Voltage Adjustment Range 11.64 to 12.36 V | ||
Isolation Voltage 1kV dc | ||
Number of Pins 7 | ||
Package Type SIP-8 | ||
Maximum Output Power 6W | ||
Weight 7g | ||
Standards/Approvals EN62368-1, EN 62368-1, RoHS, CE, cUL, UL62368-1, UKCA, C-UL, CSA, UL60950-1 | ||
Width 9.5mm | ||
Series MGW | ||
Length 22mm | ||
Depth 12mm | ||
Maximum Operating Temperature 85°C | ||
Efficiency 87% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
The Cosel DC-DC converter offers reliable voltage outputs for various applications, ensuring efficient power conversion. Its Compact design is suitable for PCB mounting, making it Ideal for space-constrained environments.
Remote ON/OFF feature enhances control over power management
Integrated overcurrent protection ensures reliability and safety under load
RoHS Regulations
