Cosel MGW DC-DC Converter, ±15V dc/ 100mA Output, 18 → 36 V dc Input, 3W, PCB Mount, +85°C Max Temp -40°C Min
- RS Stock No.:
- 171-4764
- Mfr. Part No.:
- MGW32415
- Brand:
- Cosel
Available to back order for despatch 22/10/2024
Price 1 Tube of 10
£124.46
(exc. VAT)
£149.35
(inc. VAT)
Tube(s) | Per Tube | Per unit* |
---|---|---|
1 - 4 | £124.46 | £12.446 |
5 - 9 | £120.73 | £12.073 |
10 - 24 | £118.24 | £11.824 |
25 - 49 | £115.75 | £11.575 |
50 + | £113.26 | £11.326 |
*price indicative
- RS Stock No.:
- 171-4764
- Mfr. Part No.:
- MGW32415
- Brand:
- Cosel
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Industry Standard
1"X1" (MGS15) , 1"X2" (MGS30)
High efficiency by synchronized rectification circuit (MGS10/MGS15/MGS30)
6 sided shield (MGS15/MGS30)
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in overvoltage protection circuits (MGS30)
Built-in remote ON/OFF (MGS6/MGS10/MGS15/MGS30)
Output voltage adjustability by external variable resistor (MGS15/MGS30)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
1"X1" (MGS15) , 1"X2" (MGS30)
High efficiency by synchronized rectification circuit (MGS10/MGS15/MGS30)
6 sided shield (MGS15/MGS30)
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in overvoltage protection circuits (MGS30)
Built-in remote ON/OFF (MGS6/MGS10/MGS15/MGS30)
Output voltage adjustability by external variable resistor (MGS15/MGS30)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
Industry Standard
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
Specifications
Attribute | Value |
---|---|
Output Voltage | ±15V dc |
Input Voltage Range | 18 → 36 V dc |
Power Rating | 3W |
Input Voltage Nominal | 24 V dc |
Output Current | 100mA |
Mounting Type | PCB Mount |
Isolated | Yes |
Number of Outputs | 2 |
Package | SIP 6 |
Isolation Voltage | 1kV dc |
Depth | 12mm |
Length | 17mm |
Width | 8.5mm |
Series | MGW |
Load Regulation | 750mV |
Maximum Temperature | +85°C |
Minimum Temperature | -40°C |
Efficiency | 83% |
