Cosel MGW DC/DC Converter, 15V dc, -15 V dc/ 50 mA, 5V dc Input, 4.5V Input 1.5 W, PCB, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 171-4747
- Mfr. Part No.:
- MGW1R50515
- Brand:
- Cosel
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 10 units)*
£100.08
(exc. VAT)
£120.10
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 08 February 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 - 4 | £100.08 | £10.008 |
| 5 - 9 | £97.07 | £9.707 |
| 10 - 24 | £95.07 | £9.507 |
| 25 - 49 | £93.07 | £9.307 |
| 50 + | £91.08 | £9.108 |
*price indicative
- RS Stock No.:
- 171-4747
- Mfr. Part No.:
- MGW1R50515
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 15, -15V dc | |
| Maximum Input Voltage | 5V dc | |
| Minimum Input Voltage | 4.5V | |
| Output Current 1 | 50mA | |
| Output Current 2 | 0.05A | |
| Mount Type | PCB | |
| Output Voltage 2 | 30V | |
| Number of Outputs | 2 | |
| Ripple and Noise | 200mV Pk-Pk | |
| Output Voltage Adjustment Range | 14.55 to 15.45 V | |
| Number of Pins | 5 | |
| Isolation Voltage | 1kV dc | |
| Package Type | SIP-6 | |
| Maximum Output Power | 1.5W | |
| Series | MGW | |
| Width | 8.5mm | |
| Length | 17mm | |
| Standards/Approvals | UL62368-1, UKCA, C-UL, CSA, CE, EN62368-1, cUL, EN 62368-1, UL60950-1, RoHS | |
| Depth | 12mm | |
| Weight | 4g | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 81% | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 15, -15V dc | ||
Maximum Input Voltage 5V dc | ||
Minimum Input Voltage 4.5V | ||
Output Current 1 50mA | ||
Output Current 2 0.05A | ||
Mount Type PCB | ||
Output Voltage 2 30V | ||
Number of Outputs 2 | ||
Ripple and Noise 200mV Pk-Pk | ||
Output Voltage Adjustment Range 14.55 to 15.45 V | ||
Number of Pins 5 | ||
Isolation Voltage 1kV dc | ||
Package Type SIP-6 | ||
Maximum Output Power 1.5W | ||
Series MGW | ||
Width 8.5mm | ||
Length 17mm | ||
Standards/Approvals UL62368-1, UKCA, C-UL, CSA, CE, EN62368-1, cUL, EN 62368-1, UL60950-1, RoHS | ||
Depth 12mm | ||
Weight 4g | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
Efficiency 81% | ||
- COO (Country of Origin):
- JP
Industry Standard
1"X1" (MGS15) , 1"X2" (MGS30)
High efficiency by synchronized rectification circuit (MGS10/MGS15/MGS30)
6 sided shield (MGS15/MGS30)
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in overvoltage protection circuits (MGS30)
Built-in remote ON/OFF (MGS6/MGS10/MGS15/MGS30)
Output voltage adjustability by external variable resistor (MGS15/MGS30)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
Industry Standard
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
High reliability : not built-in aluminium and tantalum electrolytic capacitor
