TRACOPOWER TIM 3.5 Isolated DC-DC Converter, ±12V dc/ ±146mA Output, 18 → 36 V dc Input, 3.5W, Surface Mount
- RS Stock No.:
- 152-7116
- Mfr. Part No.:
- TIM 3.5-2422SM
- Brand:
- TRACOPOWER
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 152-7116
- Mfr. Part No.:
- TIM 3.5-2422SM
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | ±12V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Power Rating | 3.5W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | ±146mA | |
| Mounting Type | Surface Mount | |
| Number of Outputs | 2 | |
| Package | SMD 16 | |
| Isolation Voltage | 5kV ac | |
| Depth | 10.5mm | |
| Width | 14.4mm | |
| Length | 24.3mm | |
| Series | TIM 3.5 | |
| Standards Met | EN 55022, IEC/EN/ES 60601-1 | |
| Medical Approved | Yes | |
| Efficiency | 82% | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage ±12V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 3.5W | ||
Input Voltage Nominal 24 V dc | ||
Output Current ±146mA | ||
Mounting Type Surface Mount | ||
Number of Outputs 2 | ||
Package SMD 16 | ||
Isolation Voltage 5kV ac | ||
Depth 10.5mm | ||
Width 14.4mm | ||
Length 24.3mm | ||
Series TIM 3.5 | ||
Standards Met EN 55022, IEC/EN/ES 60601-1 | ||
Medical Approved Yes | ||
Efficiency 82% | ||
