TRACOPOWER TDN 5WISM DC/DC Converter, 5V dc/ 1 A, 36V dc Input, 9V Input 5 W, Surface, 75 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 143-7578
- Mfr. Part No.:
- TDN 5-2411WISM
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£25.80
(exc. VAT)
£30.96
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £25.80 |
| 5 - 9 | £25.02 |
| 10 - 24 | £24.25 |
| 25 - 49 | £23.22 |
| 50 + | £22.18 |
*price indicative
- RS Stock No.:
- 143-7578
- Mfr. Part No.:
- TDN 5-2411WISM
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage 1 | 5V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 36V dc | |
| Minimum Input Voltage | 9V | |
| Output Current 1 | 1A | |
| Mount Type | Surface | |
| Input Ratio | 1:6 | |
| MTBF | 2960000h | |
| Number of Outputs | 1 | |
| Number of Pins | 7 | |
| Isolation Voltage | 1.6kV dc | |
| Package Type | Surface Mount | |
| Maximum Output Power | 5W | |
| Series | TDN 5WISM | |
| Width | 9.1mm | |
| Standards/Approvals | No | |
| Length | 13.2mm | |
| Depth | 9.9mm | |
| Efficiency | 80% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 75°C | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 1 5V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 36V dc | ||
Minimum Input Voltage 9V | ||
Output Current 1 1A | ||
Mount Type Surface | ||
Input Ratio 1:6 | ||
MTBF 2960000h | ||
Number of Outputs 1 | ||
Number of Pins 7 | ||
Isolation Voltage 1.6kV dc | ||
Package Type Surface Mount | ||
Maximum Output Power 5W | ||
Series TDN 5WISM | ||
Width 9.1mm | ||
Standards/Approvals No | ||
Length 13.2mm | ||
Depth 9.9mm | ||
Efficiency 80% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 75°C | ||
Traco Power DC-DC Converter, 1000mA Output Current, 1.6kV DC Isolation Voltage - TDN 5WISM Series - TDN 5-2411WISM
When your voltages need to take a step down, do it safely with this DC-DC converter from Traco Power. It draws an input between 9 and 36V DC and lowers it to give you a 5V DC output. As this is regulated with a load variation of no more than 1%, you can be sure of a constant power supply. This helps to keep sensitive circuits and components working reliably. To boost the converter's dependability, it features an isolation voltage of 1.6kV DC to keep your input and output apart. Integrated short-circuit protection provides an extra layer of safety.
Features & Benefits
• Operating temperature range between -40°C and +75°C makes it handy for consumer and industrial applications
• Remote On/Off function and efficiency of 80% makes it a power-saving option
• Typical ripple and noise of 75mVp-p minimises interference
Applications
• Audio-visual equipment
• Consumer electronics
• Telecommunications networks
• IT hubs
Is this DC-DC converter compact?
Dimensions of 13.2 (L) x 9.1 (W) x 10.2mm (D) mean this DC-DC converter is a Compact choice. Thanks to surface mounting technology and a 2.7g weight, it can be attached directly to your PCB.
