Murata Power Solutions MGJ6 DC/DC Converter, 15V dc/ 300 mA, 36V dc Input, 18V Input 4.5 W, PCB, 105 °C Max Temp -40 °C
- RS Stock No.:
- 135-5340
- Mfr. Part No.:
- MGJ6D241505DC
- Brand:
- Murata Power Solutions
Bulk discount available
Subtotal (1 tray of 30 units)*
£371.04
(exc. VAT)
£445.25
(inc. VAT)
Stock information currently inaccessible - Please check back later
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 - 4 | £371.04 | £12.368 |
| 5 - 9 | £360.74 | £12.025 |
| 10 - 24 | £350.99 | £11.70 |
| 25 - 49 | £341.75 | £11.392 |
| 50 + | £332.99 | £11.10 |
*price indicative
- RS Stock No.:
- 135-5340
- Mfr. Part No.:
- MGJ6D241505DC
- Brand:
- Murata Power Solutions
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Murata Power Solutions | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 15V dc | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 36V dc | |
| Output Current 1 | 300mA | |
| Output Current 2 | 300mA | |
| Output Voltage 2 | -5V dc | |
| Mount Type | PCB | |
| Number of Outputs | 2 | |
| Ripple and Noise | 150mV Pk-Pk | |
| Isolation Voltage | 5.7kV dc | |
| Package Type | DIP | |
| Maximum Output Power | 4.5W | |
| Depth | 9.88mm | |
| Series | MGJ6 | |
| Width | 27.81mm | |
| Standards/Approvals | ANSI, EN, RoHS, UL | |
| Weight | 12g | |
| Length | 45.47mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Efficiency | 82% | |
| Select all | ||
|---|---|---|
Brand Murata Power Solutions | ||
Product Type DC/DC Converter | ||
Output Voltage 1 15V dc | ||
Minimum Input Voltage 18V | ||
Maximum Input Voltage 36V dc | ||
Output Current 1 300mA | ||
Output Current 2 300mA | ||
Output Voltage 2 -5V dc | ||
Mount Type PCB | ||
Number of Outputs 2 | ||
Ripple and Noise 150mV Pk-Pk | ||
Isolation Voltage 5.7kV dc | ||
Package Type DIP | ||
Maximum Output Power 4.5W | ||
Depth 9.88mm | ||
Series MGJ6 | ||
Width 27.81mm | ||
Standards/Approvals ANSI, EN, RoHS, UL | ||
Weight 12g | ||
Length 45.47mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Efficiency 82% | ||
Murata MGJ Series Isolated DC-DC Converter
Murata MGJ Series of isolated DC-DC converters offer an Ideal solution for "high side" & "low side" gate drive circuits for IGBTs & MOSFETS in bridge circuits. The MGJ Series offers a choice of asymmetric output voltages and enables your application to optimise drive levels for the best system efficiency.
The MGJ Series has been designed with high isolation requirements, so can be used within motor drives & inverters and offers long service & reliability.
Features and Benefits
Optimised bipolar output voltages for IGBT / MOSFET gate drives
Continuous barrier withstand voltage 3kVDC
Surface mount package
Ultra low coupling capacitance 15pF
5.7k V dc isolation test voltage
Murata Power Solutions - 0.75W to 15W
