TRACOPOWER TMR 2 WISM DC-DC Converter, ±12V dc/ ±83mA Output, 9 → 36 V dc Input, 2W, PCB Mount, +85°C Max Temp

View all DC-DC Converters

Subtotal (1 tube of 10 units)*

£179.14

(exc. VAT)

£214.97

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 29 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s)
Per Tube
Per unit*
1 +£179.14£17.914

*price indicative

RS Stock No.:
135-1469
Mfr. Part No.:
TMR 2-2422WISM
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage

±12V dc

Input Voltage Range

9 → 36 V dc

Power Rating

2W

Input Voltage Nominal

24 V dc

Output Current

±83mA

Mounting Type

PCB Mount

Isolated

Yes

Number of Outputs

2

Package

DIP

Isolation Voltage

1.5kV dc

Width

14.9mm

Length

19mm

Depth

8.7mm

Series

TMR 2 WISM

Standards Met

IEC/UL 60950-1

Minimum Temperature

-40°C

Medical Approved

Yes

Maximum Temperature

+85°C

Traco SMD 2 Watt DC-DC Converters - TMR 2WISM Series


From TRACO POWER, a range of 2 W SMD DC-DC converters. The TMR 2 series have an ultra-wide 4:1 input and fully regulated outputs. Supplied in a compact SMD package the DC—DC converters are perfect for applications where valuable board space is limited. Capable of operating up to 70°C environment temperature at full load or up to 80°C with a 50% load derating.

Features and Benefits


• I/O-isolation 1’500 V dc
• Ultra-wide 4:1 Input 4.5 V dc to 12 V dc, 9 V dc to 36 V dc and 18 V dc to 75 V dc
• -40°C to +80°C operating temperature range
• Fully regulated outputs
• Remote On/Off

Applications


• Communication equipment
• Instrumentation
• Industrial electronics
