TRACOPOWER THM 10 DC/DC Converter, 24V dc/ 416 mA, 36V dc Input, 18V Input 10 W, PCB, 90 °C Max Temp -40 °C Min Temp DIP

View all DC-DC Converters
Bulk discount available

Subtotal (1 tube of 10 units)*

£410.54

(exc. VAT)

£492.65

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Tube(s)
Per Tube
Per unit*
1 - 4£410.54£41.054
5 - 9£398.22£39.822
10 - 24£385.91£38.591
25 - 49£369.50£36.95
50 +£353.07£35.307

*price indicative

RS Stock No.:
135-0608
Mfr. Part No.:
THM 10-2415
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Output Voltage 1

24V dc

Product Type

DC/DC Converter

Maximum Input Voltage

36V dc

Minimum Input Voltage

18V

Output Current 1

416mA

Mount Type

PCB

Input Ratio

2:1

MTBF

3850000h

Number of Outputs

1

Output Voltage Adjustment Range

21.6/28.8 V dc

Isolation Voltage

5kV ac

Package Type

DIP

Maximum Output Power

10W

Depth

10.2mm

Standards/Approvals

No

Length

31.8mm

Series

THM 10

Width

20.3mm

Maximum Operating Temperature

90°C

Minimum Operating Temperature

-40°C

Efficiency

89%

Traco Power DC-DC Converter, Single Output, 24V DC Nominal Input Voltage - THM 10 Series - THM 10-2415


When a reliable energy supply is your TOP priority, reach for this DC-DC converter from Traco Power. It lets you convert an input voltage between 18 and 36V DC into a smoothly regulated output voltage of 24V DC with a 416mA current. As it's approved for medical use and has a low leakage current of 2μA, you can rest easy that it's safe around patients, staff and equipment. With a power rating of 10W, it's suitable for use with low-energy devices and circuits.

• Compact DIP-24 package measured 31.8 (L) x 20.3 (W) x 10.2mm (D) for use when space is at a premium

• Isolation voltage of 5kV helps protect personnel and equipment

• PCB-mounted for easy installation

• 89% efficiency for low energy consumption and minimal heat build-up

• Load variation of 0.2% makes it Ideal for operating measurement equipment with precision

Applications


• Medical equipment

• Transportation industry

• Measurement devices

Is this DC-DC converter suitable for use in challenging environments?


Yes, it has a broad operating temperature range between -40°C and +90°C, so you can depend on it even in harsh conditions.
