Cosel MGFW DC-DC Converter, ±12V dc/ 1.25A Output, 9 → 36 V dc Input, 30W, PCB Mount, +85°C Max Temp -40°C Min

RS Stock No.:: 130-9354
Mfr. Part No.:: MGFW302412-R
Brand:: Cosel

Cosel MGFW DC-DC Converter, ±12V dc/ 1.25A Output, 9 → 36 V dc Input, 30W, PCB Mount, +85°C Max Temp -40°C Min

Available to back order for despatch 29/11/2024

Price Each

£46.93

(exc. VAT)

£56.32

(inc. VAT)

Units	Per unit
1 - 4	£46.93
5 - 9	£45.52
10 - 24	£44.58
25 - 49	£43.65
50 +	£42.71

RS Stock No.:: 130-9354
Mfr. Part No.:: MGFW302412-R
Brand:: Cosel

Datasheet

RS Stock No.:: 130-9354
Mfr. Part No.:: MGFW302412-R
Brand:: Cosel

Datasheet

Attribute	Value
Output Voltage	±12V dc
Input Voltage Range	9 → 36 V dc
Power Rating	30W
Input Voltage Nominal	24 V dc
Output Current	1.25A
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	2
Output Voltage Adjustment Range	11.765 → 12.492V
Isolation Voltage	500V dc
Width	50.8mm
Length	25.4mm
Depth	9.9mm
Series	MGFW
Load Regulation	480mV
Efficiency	88%
Standards Met	CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
Minimum Temperature	-40°C
Maximum Temperature	+85°C

Attribute	Value
Output Voltage	±12V dc
Input Voltage Range	9 → 36 V dc
Power Rating	30W
Input Voltage Nominal	24 V dc
Output Current	1.25A
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	2
Output Voltage Adjustment Range	11.765 → 12.492V
Isolation Voltage	500V dc
Width	50.8mm
Length	25.4mm
Depth	9.9mm
Series	MGFW
Load Regulation	480mV
Efficiency	88%
Standards Met	CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
Minimum Temperature	-40°C
Maximum Temperature	+85°C

Cosel MGFW DC-DC Converter, ±12V dc/ 1.25A Output, 9 → 36 V dc Input, 30W, PCB Mount, +85°C Max Temp -40°C Min

MGFW Series, On/Off Remote Function

Features and Benefits

MGFW Series, On/Off Remote Function

Features and Benefits
